• Model NO.：ZQ-B600-6
• Certification：CE, ISO9001:2008
• After-sales Service：Engineers Available to Service Machinery Overseas
• Number of Cavity：6 Cavities
• Max.Output：7000-8000 Bottles,Hour
• Products Volume：100-600ml Pet Bottle
• Auto Systems：Fully Automatic
• Delivery Date：30 Days
• After-Sales Service Provided：Engineers Available to Service Machinery Overseas
• HS.Code：8477309000
• Transport Package：General Packing
• Specification：Max: 600ml
• Trademark：ZQ
• Origin：HUANGYAN, CHINA
• HS Code：8477300000
• Production Capacity：30 Set,Month

CONTAINERNumber of cavity2 cavities3 cavities4 cavities6 cavitiesOutput2400-2700 pcs/hr3000-3300 pcs/hr5500-6000 pcs/hr7000-8000 pcs/hrMax. container volume0.6L0.6L0.6L0.6LMax. neck diameter38mm38mm38mm28-30mmMax. container diameter65mm65mm65mm60mmMax. container height230mm230mm230mm260mmELECTRICAL SYSTEMNumber of lamp21pcs28pcs35pcs56pcsMax. heating power21kw28kw32kw34kwInstallation power24kw28kw32kw48kwActual power consumption14kw18kw22kw24kwAIR SYSTEMOperatating pressure7-9kg/cm²7-9kg/cm²7-9kg/cm²7-8kg/cm²Low pressure consuming1000Ltr/min1200Ltr/min1600Ltr/min1600Ltr/minBlowing pressure25-35kg/cm²25-35kg/cm²25-35kg/cm²25-35kg/cm²High pressure consuming1500-2000 Ltr/min2000-2200 Ltr/min2200-2500 Ltr/min2000-2200 Ltr/minCHILLER WATEROperating pressure5-6 kg/cm²5-6 kg/cm²5-6 kg/cm²5-6 kg/cm²Temperatuer10º C10º C10º C10º CConsuming5600kcal/hr5600kcal/hr5600kcal/hr8000kcal/hrFlow rater30Ltr/min30Ltr/min30Ltr/min88Ltr/minMACHINEMachine dimension2.3x1.5x1.7(m)3.5x1.95x2.1(m)3.7x1.95x2.1(m)5.0x2.1x2.1(m)Machine weight1.8ton3.6ton3.7ton5.0tonNote: The specifications are subject to change without notice for the further improvement.
Note: Custom production accepted. Any client idea tried.

Plastic Bottle Maker Automatic PET Blow Molding Machine for 600ml bottles,picture
