• Model NO.：FD-2A
• Gun Type：Injection&Spraying
• Color：Customized
• Heater Power：4500W Each One
• The Ratio of Raw Material：1: 1(Fixed)
• Heating Hose Power：1000W,15m
• Gun Clean：Self Clean by Air
• Air Motor Diameter：5 Inch
• Max Working Pressure：13.8 Mpa (138 Bar)
• Max Output：9kg,Min (17.6 Lb,Min)
• The Viscosity Range of Raw Material：200-1000cps (Under The Operate Temperature)
• Transport Package：Plywood Crate
• Specification：CE
• Trademark：SAIJUN
• Origin：Shandong Province, China
• HS Code：847
• Production Capacity：50 Set ,Month

Basic Info.

Model NO. FD-2A Gun Type Injection&Spraying Color Customized Heater Power 4500W Each One The Ratio of Raw Material 1: 1(Fixed) Heating Hose Power 1000W/15m Gun Clean Self Clean by Air Air Motor Diameter 5 Inch Max Working Pressure 13.8 Mpa (138 Bar) Max Output 9kg/Min (17.6 Lb/Min) The Viscosity Range of Raw Material 200-1000cps (Under The Operate Temperature) Transport Package Plywood Crate Specification CE Trademark SAIJUN Origin Shandong Province, China HS Code 847 Production Capacity 50 Set /Month

Product Description

Polyurethane Foaming electromotion Machine

Web: saijunpu.en.made-in-china.com

Why choose us?
1.Our product quality assurance, user feedback well, our products have passed the quality system certification in Europe.

2.Our service system is perfect, we have professional R & D team, the system's production line, a professional electrical engineer, experienced, our service staff will reply to you in the first time in the machine during use any queries. If the machine has any problems, we will within 12 hours to solve the problem

Standard configuration:

Proportion Fixed Mainframe: 1 set
Self-cleaning spray/injecting gun: 1 set
Heating and preserved pipe: 49.2 feet (15m)
Connecting pipe for spray gun: 4.9 feet (1.5m)
Transfer pump: 2 sets



Technical parameter:
Electrical requirements single-phase: 220V 50Hz 30A
Compressed air requirements: 116psi(0.7Mpa) ,28CFM(1m³/min)

Output: 8kg/min



Shipping parameter:
G.W.: 110kg
Host and accessories box Volume: 1500*600*600mm
Heating box Volume: 900*700*1150mm
