Polyurethane Injection Insulation Foam Machine (FD-211A)
Jinan Saijun CNC Technology Co., Ltd.- Type：Polyurethane Foam Machine
- Raw Material：Mixing
- Principle：High-Pressure Air Type
- Automation：Automatic
- Computerized：Computerized
- Certification：CE
Base Info
- Model NO.：FD-211A
- Max Heating Hose：16m
- Gun Type：Injection,Filling
- Gun Clean Mode：Self Clean by Air
- Color：White
- Whole Power：6500W
- Transport Package：Plywood Crate
- Specification：CE
- Trademark：SAIJUN
- Origin：China
- Production Capacity：50 Set ,Month
Description
| Technical Data |
| Model FD-211 |
| Max working pressure10.8MPa(108 bar) |
| Max hose length16m (52 feet) |
| Max fluid temperature85C (185F) |
| Max output6kg/min (13.2 lb/min) |
| Air pressure request 1.25mpa(12.5bar,181psi) |
| Power supply 1-ph 220V 3-ph 380V |
| Heater power 3000W each one |
| Heater hose power No power |
| Power 6500W |
| Net weight 120kg |
| Machine size 1500x600x600/600x450x960 |
| Standard configuration |
| Proportion Fixed Mainframe 1 set |
| Self-cleaning spray gun 1 set |
| Thermal injecting hose 26.2 feet (8m) |
| Heating unit 1 set |
| Connecting hose from thermal insulation hose to gun 5 feet(1.5m) |
| Connecting hose from machine to heating unit 10 feet (3m) |
| Rings and Tools |
| Operation manual |
