Polyurethane Foaming Spray Nozzle Machine (FD-311A)

Jinan Saijun CNC Technology Co., Ltd.
  • Type:Polyurethane Foam Machine
  • Raw Material:Mixing
  • Principle:High-Pressure Air Type
  • Automation:Automatic
  • Computerized:Computerized
  • Certification:CE

Base Info

  • Model NO.:FD-311A
  • Gun Type:Injection&Spray
  • Color:Customized
  • Heater Power:3000W Each One
  • The Ratio of Raw Material:1: 1(Fixed)
  • Heating Hose Power:1000W,15m
  • Gun Clean:Self Clean by Air
  • Air Motor Diameter:5 Inch
  • Max Working Pressure:13.8 Mpa (138 Bar)
  • Max Output:8kg,Min (17.6 Lb,Min)
  • The Viscosity Range of Raw Material:200-1000cps (Under The Operate Temperature)
  • Transport Package:Plywood Crate
  • Specification:CE certificate
  • Trademark:Saijun
  • Origin:Shandong Province, China
  • Production Capacity:50 Set ,Month

Description

Technical Data
The ratio of raw material 1:1(Fixed)
The viscosity range of raw material

200-1000CPS (Under the
operate temperature)
Max working pressure 213.8MPa (230 bar)
Max fluid temperature 85C(185F
Max Output 9kg/min (22 lb/min)
Air motor diameter 6 feet
Heater power 4500W each one
Heating hose power 1000W/15m
Whole power 10500W
Voltage 230V 1-ph/400V 3-ph
Operate temperature 0C-70C
Clean mode Self-clean by air
Max heating hose length 295 feet (90m)
Pneumatic source 1MPa(10 bar,145 psi)
Machine size 900mm*820mm*1150mm
           1450mm*400mm*550mm
Gross weight 220KG

Standard configuration
Proportion Fixed Mainframe 1 set
Self-cleaning foaming(spray or injection)gun 1 set
Feeding pump 2 sets
Heating hose 49.2 feet (15m)
Connecting hose from feeding pump to machine 10 feet(3m)
Connecting hose from heating hose to gun 5 feet(1.5m)
Rings and Tools

Item FD-411 Polyureathane foam machine
Price(FOB qingdao) XX$USD
Terms of payment 100%  T/T in advance
MOQ 1set
Delivery time Within 30 working days after T/T
warranty 18 mouths
