• Max Hose Length：295feet (90m)
• Pneumatic Source：1mpa(10bar, 145psi)
• Delivery Time：Within 15 Working Days After Tt
• Max Output：10kg,Min(22 Lb,Min)
• HS Code：8477800000
• Production Capacity：50 Sets,Month

Basic Info.

Max Hose Length 295feet (90m) Pneumatic Source 1mpa(10bar, 145psi) Delivery Time Within 15 Working Days After Tt Max Output 10kg/Min(22 Lb/Min) HS Code 8477800000 Production Capacity 50 Sets/Month

Product Description

FD-411A
Item FD-411A Polyurethane foaming machine.
MOQ 1 set.
Delivery time Within 15 working days after T/T.
Standard configuration Proportion Fixed Mainframe 1 set
Self-cleaning spray gun 1 set
Feeding pump 2 sets
Heating hose 49.2 feet (15m)
Connecting hose from feeding pump to machine 10 feet(3m)
Connecting hose from heating hose to gun 5 feet(1.5m)
Rings and Tools
Technical Data The ratio of raw material 1: 1(Fixed)
The viscosity range of raw material 200-1000CPS (Under the operate temperature)
Max working pressure 23MPA (23 bar)
Max fluid temperature 88ºC (190ºF)
Max output 10kg/min (22 lb/min)
Air motor diameter 6 feet
Heater power 4500W each one
Heating hose power 1000W/15m
Whole power 7500W
Voltage 230V 1-pH/400V 3-pH
Operate temperature 0ºC-70ºC
Clean mode Self-clean by air
Max heating hose length 295 feet (90m)
Pneumatic source 1MPA (10 bar, 145 psi)
Packing size 900mm*820mm*1150mm
1450mm*400mm*550mm
Gross weight 220KG
