Hydraulic Polyurethane Foaming Machine Fd-511 for Building Indulation
Jinan Saijun CNC Technology Co., Ltd.- Type：Polyurethane Foam Machine
- Raw Material：Mixing
- Principle：High-Pressure Air Type
- Automation：Automatic
- Computerized：Computerized
- Certification：CE
Base Info
- Model NO.：FD-511
- Max Heating Hose：94m
- Gun Type：Injecting,Spraying
- Gun Clean Mode：Self Clean by Air
- Color：White
- Whole Power：10500W
- Material：ISO and Poly
- Output：12kg,Min
- Machine Type：Hydraulic
- Gross Weight：350kg
- Transport Package：Plywood Crate
- Specification：CE
- Trademark：SAIJUN
- Origin：China
- HS Code：84778
- Production Capacity：50 Set ,Month
Description
| Technical date | |
| Model FD-511 | |
| Max working pressure | 23MPa(230 bar) |
| Max hose length | 90m/120m(injecting) |
| Max fluid temperature | 88C190F |
| Max output | 12kg/min (17.6 lb/min) |
| Air pressure request | 1MPa (10 bar, 145psi) |
| Whole power | 13500W |
| Heater power | 6000W each one |
| Heater hose power | 1000W/15m |
|
Voltage |
1-ph230V/3-ph 400V/3-ph380V |
|
Gross weight Net weight |
350kg 300kg |
|
Machine size 115*68*139mm 600.450.960mm |
|
|
CMB:1.4m3 |
|
| Standard configuration |
| Proportion Fixed Mainframe 1 set |
| Self-cleaning foaming(spray or injection)gun 1 set |
| Feeding pump 2 sets |
| Heating hose 49.2 feet (15m) |
| Connecting hose from feeding pump to machine 10 feet(3m) |
| Connecting hose from heating hose to gun 5 feet(1.5m) |
| Rings and Tools |
| Item | FD-511 Polyurea foam hydraulic machine |
| Price(FOB qingdao) | XX$USD |
| Terms of payment | 100% T/T in advance |
| MOQ | 1set |
| Delivery time | Within 30 working days after T/T |
| warranty | 18 mouths |
