High Speed 5 Liter Plastic Pet Bottle Making Machine Price by CE
TAIZHOU GUANGDU PLASTIC MACHINERY CO., LTD.- Type:Stretch Blow Molding Machine
- Raw Material:PET
- Making Method of Parison:Injection Molding
- Automation:Automatic
- Computerized:Computerized
- Certification:CE, ISO9001:2008
Base Info
- Model NO.:ZQ-B5000-4
- Number of Cavity:4 Cavities
- Max Volume:5 Liter Bottles
- Output:2800-3500 Bph
- Delivery Date:50 Days
- Warranty:12 Months
- Auto Systems:Fully Automatic
- After-Sales Service Provided:Engineers Available to Service Machinery Overseas
- Transport Package:General Packing
- Specification:Max: 5000ml
- Trademark:ZIQIANG
- Origin:Huangyan, China
- HS Code:8477300000
- Production Capacity:30 Sets,Month
Description
CONTAINERNumber of cavity 4cavities Output 2800-3500 pcs/hr Max.container volume 5L Max.neck diameter 45-80mm Max.container diameter 180mm Max.container height 350mm ELECTRICAL SYSTEM Number of lamp 60pcs Max.heating power 60kw Installation power 100kw Actual power consumption 36kw AIR SYSTEM Operatating pressure 7-9kg/cm² Low pressure consuming 2600Ltr/min Blowing pressure 25-35kg/cm² High pressure consuming 4500-5000 Ltr/min CHILLER WATER Operating pressure 5-6 kg/cm² Temperatuer 10ºC Consuming 6600kcal/hr Flow rater 45Ltr/min MACHINE Machine dimension 5.6x2.1x2.1(m) Machine weight 5.5ton Note: The specifications are subject to change without notice for the further improvement.
Note: Custom production accepted. Any client idea tried.
