560 Ton High Efficiency Energy Saving Injection Molding Machine (AL-U/560C)

Ningbo Beilun Allway Machinery Co., Ltd.
  • Type：Injection Machine
  • Structure：Horizontal
  • Plastic Type：Thermoplastic
  • Plasticizing Way：Screw Type
  • Clamping Way：Hydraulic
  • Automation：Automatic

Base Info

  • Model NO.：AL-U,560C
  • Computerized：Computerized
  • Certification：CE
  • Servo System：Energy Conservation
  • Transport Package：Straightly Stand on Wooden Shelf
  • Specification：CE, SGS, ISO9001: 2008, CQC
  • Trademark：ALLWAY
  • Origin：Ningbo, China
  • HS Code：8477101090
  • Production Capacity：500 PCS,Year

Description

 INTERNATIONAL CALSS NO                               560/3380SPECIFICATIONS                                U/560CScrew type  ABCD Injection   Screw diameter mm 75808590 Screw L/D ratio L/D23.52220.719.6 Shot volume(therretical cm31727196522182487 Injection weight(ps) g1572178820182263 Injection rate g/s388442499559 Injection pressure Mpa191168149133 Screw Speed rpm                                     130 Clamping Unit   Clamping force KN                                    5600 Open stroke mm                                    850 Space between tie bars(W*H) mm                               830*830 Max.Mould height mm                                    850 Min.Mould height mm                                    330 Ejector stroke mm                                    240 Ejector force KN                                    150 Others   Pump max. pressure Mpa                                      16 Pump motor power KW                                      55 Heating power KW                                      31.4 Numbers of heating area segment                                      5+1 Machine dimension(L*W*H)m                             8.45*2.15*2.84 Oiltank cubage L                                     795 Machine weight t                                      21
