High Speed Long Service Life Rotary Die Double Rewinder Film Blowing Machine with Ce
Zhejiang Songshan Machinery Co., Ltd.- Raw Material：HDPE, LDPE, LLDPE; Virgin and Recycled
- Screw Diameter：65mm
- Certification：ISO9001:2008
- Condition：New
- Warranty：12 Months Guarantee
- film Thickness：0.008mm-0.15mm
Base Info
- Automatic：No
- Blow Moulding Type：Extrusion Blow Moulding
- Power(W)：22kw
- Color：as Required
- Ld Ratio：30:1
- film Width：1200mm
- Weight：10000kg
- Transport Package：Plastic Film; , Wooden Boxes, or as Required
- Trademark：songshan
- Origin：Zhejiang, China (Mainland)
Description
Model
SJ-55
SJ-65
SJ-75
Features
Raw Material
HDPE, LDPE, LLDPE; Virgin and Recycled
Film Width
800mm
1200mm
1500mm
Average Output
45Kgs
65Kgs
85Kgs
Film Thickness
0.008mm-0.15mm
Dimension
5×3.5×4.5M
6×4×5.5M
7×5×7M
Extrusion Unit
Screw Diameter/LD ratio
55mm
30:1
65mm
30:1
75mm
32:1
Motor
15KW
22KW
37KW
Gearbox
146
173
200
Die Head Type
Rotary Die Head
Die Size
80/160mm
160/260mm
400mm
Film
Taking-up Tower
Upper Tower Type
Up and down; embossing roller and gusseting
Roller Length
900mm
1400mm
1800mm
Roller Working Way
Opened and Tightened By Air Cylinders
Winding Station
Winder Type
Double winding station fraction type
Rollers
900mm
1400mm
1700mm
Max. Winding Diameter
650mm
Control Panel
Electronics
Top China Brand
