680 Ton High Efficiency Energy Saving Injection Molding Machine (AL-UJ/680C)
Ningbo Beilun Allway Machinery Co., Ltd.- Structure：Horizontal
- Plastic Type：Thermoplastic
Base Info
- Model NO.：U,680C
- Plasticizing Way：Screw Type
- Clamping Way：Hydraulic & Mechanical
- Automation：Automatic
- Computerized：Computerized
- Certification：CE, ISO9001:2008, CQC
- Servo System：Energy Conservation
- Transport Package：Ningbo Beilun Allway Machinery Co., Ltd. Belong to
- Specification：CE, SGS, ISO9001: 2008, CQC
- Trademark：ALLWAY
- Origin：Ningbo China
- HS Code：8477101090
- Production Capacity：500 PCS,Year
Description
INTERNATIONAL CLASS NO680/4680 U STYLE SPECIFICATION U/680C Screw type Unit A B C D Injection Unit Screw diameter mm 90 95 100 105 Screw L/D ratio L/D 23.2 22 20.9 19.9 Shot volume(therretical) cm 3 2544 2835 3140 3461 Injection weight(PS) g 2315 2580 2858 3149 Injection rate g/s 552 612 679 748 Injection pressure M Pa 184 165 149 130 Screw speed rpm 150 Clamping unit Clamping force KN 6800 Open stroke mm 900 Space between tie-bars(WxH) mm x mm 895x895 Max mould height mm 900 Min mould height mm 350 Ejector stroke mm 250 Ejector force KN 150 Others Max pump pressure M Pa 16 Servo system power KW 37+37 Heating power KW 42.95 Numbers of heating area 5+1 Machine demension(LxWxH) m 10.60x2.28x2.89 Oil tank cubage L 1100 Machine weight t 30.8 Remarks:The company reserves the right to modify the specification parameters without notice.
