• Model NO.：BYSJ
• High Tech Extrusion Line：PLC Control System
• Transport Package：PVC Film
• Specification：CE SGS
• Trademark：BOYU
• Origin：Wuxi
• HS Code：8477209000
• Production Capacity：30 Machine Lines ,Month

Basic Info.

Model NO. BYSJ High Tech Extrusion Line PLC Control System Transport Package PVC Film Specification CE SGS Trademark BOYU Origin Wuxi HS Code 8477209000 Production Capacity 30 Machine Lines /Month

Product Description

Best quality pvc extruder machine upvc profile extrusion machine



Model	YF180	YF240	YF600	YF800	YF1000
Max.Width of product(mm)	180	300	600	800	1000
Extruder mode	SJZ51/105	SJZ65/132	SJZ80/156	SJZ80/156	SJZ92/188
Extrusion capacity(kg/h)	150	180	360	360	600
Motor power(kw)	18.5	37	55	55	110
Total length(m)	18	22	26	28	32

Composition of 65/132 Connical Twin screw extrusion line


Item	Quantity
SJSZ- XX Twin Screw Extruder with Automatic Feeding System	One set
Die Mold & Stock Mold	One set
Vacuum Calibrarion Table	One set
Haul-off and Cutter Unit	One set
Stacker	One set
Electric Control System	One set

Main electric part supplier :
Inverter:ABB
Contactor:Schneider
Air Switch:Schneider
Relay:Omron
Temperature controller:RKC
Electric control system:PLC
2.YF240 Calibration platform
Exterior dimension:Lx W x H:6000x1100x1000mm (adjustable)
Vacuum pump:4x5.5KW,Water pump:2×4KW;Origin:Made in qingdao, China
Three direction adjustment:Forward and Backward with 0.75 Kw motor,Range:±1000mm
Up and down, left and right manually adjusted;Range:Up and down:±150mm
3.Haul-off and cutter (combined)

Haul-off speed:0-3m/min;Motor power:5.5KW;Caterpillar width:210mm;
Caterpillar length:2200mm;Pneumatic clamp;
Cutter:Motor power:2.2KW;Scrap collecting motor power:1.5KW;Diameter of saw:500mm;
Cutting range:200mm;With scrap collecting device;
4.Mould -accoring to customer sample or drawing


Our Services
1) We recommend of machine and auxiliary equipments and relevant budgeting, human resources allocation and budgeting.
2) We would like to answer any inquiry within 36 hours and it will be solved as soon as possible.
3) The buyer can send the worker to our company for training.
4) The Seller supplies the complete technical support documents and the relative drawings of the electric components written in Chinese and English.
5) Our engineer can be to the Buyer's company for installation and testing the lines.
Company Information
Our factory is near Shanghai city.We have CE and be verified by SGS.Some production lines have got test reports by SGS company.

We also manufacture WPC machine,PVC/WPC foamed board machine, plastic profile/panel/ceiling machine, plastic pelletizing line, shredder, mixer, crusher and so on.

Our boss is a technologist in the field near about 20 years.So we pay more attention to design, technology and quality.Now we are expanding market abroad.So our prices are competitive.

In last few years we have exported to Russia, Ukraine, South Africa, Nigeria, Zambia, Saudi Arabia, Egypt, Jordan, Pakistan, Bangladesh, Uzbekistan, Argentina, Mexico, etc.
For some main parts, we usually use Siemens/ABB/Omron/ Schneider brands in order to ensure better quality.
