Powder Coating Twin Screw Extruder
YANTAI WUTAI CHEMICAL EQUIPMENT CO., LTD.- Type:Powder Coating Extruder
- Plastic Processed:Epoxy and Polyster Resin
- Product Type:Powder Coating Extruder
- Feeding Mode:Multiple Feed
- Assembly Structure:Integral Type Extruder
- Screw:Twin-Screw
Base Info
- Model NO.:ZSJ-53
- Engagement System:Full Intermeshing
- Screw Channel Structure:Deep Screw
- Exhaust:Exhaust
- Automation:Non-Automatic
- Computerized:Non-Computerized
- Heating:Electroc
- Warranty:24months
- Certificate:Ce
- Transport Package:Standard Export Package
- Specification:300kg per hour
- Trademark:wutai
- Origin:China
- Production Capacity:200sets,Year
Description
Direct water coolingDimension(m) 2.0*0.65*1.7 2.3*0.7*1.9 2.3*0.7*1.9 2.7*0.8*2.0 2.9*0.9*2.0 3.8*0.8*2.1
This extruder is co-rotating twin screw extruder ,materials can achieve ideal dispersed and kneaded effect after fully hot-melted under the precise intermeshing action of the conveying elements and kneading elements on the screws.
Main Features
*High output capacity and excellent mixing efficiency, glossiness can increased 3-5 degree than normal extruder.
*Clamshell barrel has high efficient heat-exchange and automatic temperature control system
*Barrel is opposite open type,easy to clean
*Hopper with screw shaft ensure the uniform feeding
*Automatic alarm of lubricating oil control system
*Advanced two way PID temperature control system with tolerance ±2ºC
*The clamshell barrel cooled by automatic recycle filter water (optional equipment)
*Screw sleeve is segment liner design
*3 types electric control type for your choose
(a) Normal control - ZSJ-A
(b) design according to the EU standard - ZSJ-B
(c) Touch screen computer display and PLC control - ZSJ-C
*Gearbox designed in lower noise and high speed
*To void the raw material jam in the hopper , the feeder is with vibrate or swing system(option equipment)
*There is strong permanent metal magnetic detector system
This extruder is co-rotating twin screw extruder ,materials can achieve ideal dispersed and kneaded effect after fully hot-melted under the precise intermeshing action of the conveying elements and kneading elements on the screws.
Main Features
*High output capacity and excellent mixing efficiency, glossiness can increased 3-5 degree than normal extruder.
*Clamshell barrel has high efficient heat-exchange and automatic temperature control system
*Barrel is opposite open type,easy to clean
*Hopper with screw shaft ensure the uniform feeding
*Automatic alarm of lubricating oil control system
*Advanced two way PID temperature control system with tolerance ±2ºC
*The clamshell barrel cooled by automatic recycle filter water (optional equipment)
*Screw sleeve is segment liner design
*3 types electric control type for your choose
(a) Normal control - ZSJ-A
(b) design according to the EU standard - ZSJ-B
(c) Touch screen computer display and PLC control - ZSJ-C
*Gearbox designed in lower noise and high speed
*To void the raw material jam in the hopper , the feeder is with vibrate or swing system(option equipment)
*There is strong permanent metal magnetic detector system
