Chsj-35/40/45e Film Blowing and Printing Machine

HEBEI CHENGHENG PLASTIC MACHINERY TECHNOLOGY CO., LTD.
  • Type：High and Low Pressure Film Blowing Machine
  • Raw Material：HDPE
  • Maximum Folding Width of Film：1500mm
  • Screw Diameter：45mm
  • Automation：Automatic
  • Computerized：Computerized

Base Info

  • Model NO.：CHSJ-35,40,45E
  • Machine Weight：4T
  • Certification：CE, ISO9001:2008
  • L/D Ratio of Screw：L,D 30:1
  • The Raw Material：LDPE,HDPE
  • Die Diameter：40-160mm
  • Packing Details：Wooden Cases
  • Delivery Time：20-25 Working Days
  • Payment Term：T,T
  • The Die Diameter：40-160mm
  • Extrusion Capacity：25-50kg,H
  • Transport Package：Wooden Cases
  • Specification：SGS
  • Trademark：CHENGHENG
  • Origin：China
  • HS Code：8477309000
  • Production Capacity：10PCS,Month

Description

ModelCHSJ--35ECHSJ--40ECHSJ--45ERaw materialLDPE,HDPELDPE,HDPELDPE,HDPEDiameter of screwΦ35 mmΦ40 mmΦ45 mmL/D ratio of screwL/D 30:1L/D 30:1L/D 30:1Main motor power7.5kw11kw15kwExtrusion capacity25 kg/h35 kg/h50 kg/hDie diameter40-80 mm80-130 mm100-160 mmFilm width600 mm800 mm1000 mmFilm thickness0.003-0.1 0mm0.003-0.10 mm0.003-0.10 mmPrinting length250-1000 mm250-1000 mm250-1000 mm

Our Service:
1.Free installation and ajustment.(for consumers purchase more than $100000 only)
2.Five years free after-sales service and mechanical parts lifetime warranty.
3.We will offer you the professional answers about the relating machines in 24 hours.
