3 Layer Co-Ex Film Extrusion Machine
RUIAN YUNBANG MACHINE CO., LTD.- Warranty：One Year
- Type：Multi-Layer Co-extrusion Film Blowing Machine
- Raw Material：PE
- Maximum Folding Width of Film：1500mm
- Screw Diameter：60mm
- Automation：Automatic
Base Info
- Model NO.：MB-1500Q
- Computerized：Computerized
- Machine Weight：25 T
- Certification：CE, ISO9001:2008
- Screw No.：3 Screw
- Max. out Put：180 Kgs,H
- Main Motor Power：37kw (3 PCS)
- Max. Screw Speed：100 R,Min
- Gear Box Type：200 Type
- Transport Package：Film Wrap
- Specification：machine size: 10*4*9.5 M
- Trademark：YUNBANG
- Origin：Zhejiang, China
- HS Code：84773010
- Production Capacity：60 Set,Year
Description
3 layer co-extrusionFilm thickness(mm) 0.012-0.2 (can make the thickness as customer requirement) 0.012-0.25 Max output(kg/h) 140 MLLDPE/LLDPE/LDPE/EVA Screw Diameter(mm) 55*3 30:1 Extruder Driving power 22 Hydraulic/Manual twin-station changing screen quickly Die structure Optional:IBC system(Internal Bubble Cooling) Air-ring structure dual-lip Reversing Haul-off system Film Turning Mode ±180/±360 Angle of Reversing ±180 Take-off and wond-up Speed 80m/min Total power 85 The machine can realize PLC programming and controlling by touch
