218ton 500g Hydraulic Injection Moulding Machine with Servo System
Ningbo Kingway Machinery Co., Ltd.- Type：Preform Injection
- Structure：Horizontal
- Plastic Type：Thermoplastic
- Automation：Automatic
- Computerized：Computerized
- Clamp Force: 118ton：Shot Weight: 181g
Base Info
- Model NO.：KW218S
- Transport Package：Plastic Film
- Trademark：Kingway
- Origin：Ningbo China
- HS Code：8477101090
- Production Capacity：50 Sets,Month
Description
Technical parameterItem Unit Model KW218 Injection unit Screw type / A B C Screw diameter mm 45 50 55 Shot volume(theoritical) cm3 382 471 570 Injection weight (PS) g 344 424 513 Injection rate g/s 124 154 186 Injection pressure Mpa 181 147 122 Screw rotation speed r.p.m 190 Clamping unit Clamping force KN 2180 Open stroke mm 475 Space between tie bars(W*H) mm 520*520 Max. mould height mm 530 Min. mould height mm 200 Ejector stroke mm 140 Ejector force KN 46 Others Max. Pump pressure Mpa 14 Pump motor power KW 18.5 Heating power KW 14 Machine dimension(L*W*H) m 5.3*1.45*2.1 Machine weight t 7
Application:
The machines applicable industries include general houseware, electronic products, auto parts, packaging, toys and building components etc.
