Chromed Tie Bar for Injection Molding Machine
Ningbo Jinyi Precision Machinery Co., Ltd.- After-sales Service：Online
- Warranty：12 Months
- Standard：DIN, GOST, GB, ANSI, BS
- Technics：Machining
- Feature：Durable
- Material：Alloy Steel
Base Info
- Model NO.：JYAC05
- Max Length：1000mm
- Hardness：55HRC
- Straightness：0.02mm,M
- Surface Roughness：Ra0.4
- Application：Injection Molding Machine
- Package：Wooden Case
- Waranty：12 Months
- Treatment：Chrome Plating
- Transport Package：Wooden
- Specification：d16~d500mm
- Trademark：JY
- Origin：China
- HS Code：84779000
- Production Capacity：2000set,Month
Description
Product FeaturesBrand JINYI Product Name Tie Bar Base Material 41CrMo(High-quality Alloy Structural Steel) Suitable Machine Injection Molding Machine Available Length 10,000mm Process Method Chrome Plating(Electroplate)
Our second factory, Ningbo Lichao Tiebar Precision Machinery Co., Ltd. is specialized in manufacturing nitriding and chrome plated tie bars together with matching guide rods, piston rods, nuts and other accessories for injection molding machine, die casting machine and forging machine.
Technical Parameters
Product Name : Tiebar or Tie Bar
Material: JYN3
Heat Treatment: Quench & Temper
Surface Treatment: Nitrided or Chrome Plated
Chrome Thickness: 0.05mm
Surface Hardness: > 55 HRC
Max. Diameter: 600mm
Max. Length: 10,000mm
Application
Injection molding machine, die casting machine and forging machine, etc.
Manufacturing Process
Here is a comparison of the different manufacturing processes for nitrided and bimetallic tiebars.
FAQ:
Q1. What's your MOQ?
1PC or SET
Q2. Can I place the customized order for different sizes, materials, structure….?
Yes, all customized orders are welcomed.
Q3. Could I get a QC report before delivery?
Yes, the specific QC reports will be sent to you before delivery.
Q4. Can I have our own logo or label on our product?
Yes,we can laser your logo or code number on your product.
Q5. How long is your guarantee?
1year,2 years,5 years base on different requirement.
Q6. How to reach you for other questions?
Please feel free to contact us through E-mail, call or visiting our factory as below address.
Our second factory, Ningbo Lichao Tiebar Precision Machinery Co., Ltd. is specialized in manufacturing nitriding and chrome plated tie bars together with matching guide rods, piston rods, nuts and other accessories for injection molding machine, die casting machine and forging machine.
Technical Parameters
Product Name : Tiebar or Tie Bar
Material: JYN3
Heat Treatment: Quench & Temper
Surface Treatment: Nitrided or Chrome Plated
Chrome Thickness: 0.05mm
Surface Hardness: > 55 HRC
Max. Diameter: 600mm
Max. Length: 10,000mm
Application
Injection molding machine, die casting machine and forging machine, etc.
Manufacturing Process
Here is a comparison of the different manufacturing processes for nitrided and bimetallic tiebars.
