• Model NO.：SJ
• Computerized：Computerized
• Machine Weight：4T
• Certification：CE, ISO9001:2008
• Film Thickness(mm)：HD:0.008-0.08
• Max Extrusion Output HD：80kg,Hr
• Gear Box：200
• Screw L/D Ratio：28:1
• Transport Package：as Requirement
• Specification：CE. SGS
• Trademark：YunBang
• Origin：China
• HS Code：8477309000
• Production Capacity：20 Sets,Month

SJ series high and low pressure film blowing machine

Main Technical ParametersModelSJ50SJ55SJ60SJ65 Suitable MaterialHDPE/LDPE/LLDPE Max Film Width(mm)60080010001200 Film Thickness(mm)HD:0.008-0.08 LD:0.02-0.15 Max Extrusion Output HD40kg/hr50kg/hr60kg/hr80kg/hr                                  LD50kg/hr60kg/hr70kg/hr100kg/hr Extrusion unit  Gear Box146173173200 Screw Diameter(mm)φ50φ55φ60φ65 Screw L/D Ratio28:128:128:128:1 Screw's Material38 CRMOALA Barrel's Material38 CRMOALA Barrel's Cooling Fan250W×2370W×2370×2370×2 Thermo Control (zone)3334 Driving Motor (kw)1118.52230 Extrusion Die   Die Size (mm)HD:φ60HD:φ80HD:φ100HD:φ120 LD:φ150LD:φ180LD:φ220LD:φ250 Die Rotary Device360°Continue Rotary  360° Screen ChangerStandard manual Thermo Control (zone)2222 Air Ring (mm)φ620φ760φ760φ760 Cooling Blower (kw)1.52.22.23 Center Steady Stick1 PCS Take-UP Unit   Roller Width (mm)φ138×650φ138×850φ138×1100φ138×1300 Embossing Roller Width550mm750mm1000mm1200mm Take-UP Motor (kw)0.751.11.11.5 Take-UP Speed(M/min)10-6010-6010-6010-60 Height adjustable type700mm Winding Unit   Type OF WinderSurface Friction Winder Roller Width (mm)70090011001300 Winding Motor (N.M)6101016 Winding Speed(M/min)10-6010-6010-6010-60 Voltage380V, 50HZ, 3PHASE Cover Dimensions (m)4.5×2.0×4.34.5×2.2×4.55×2.5×4.85.5×2.8×5.2  Price USD10500  USD13000 USD15000 USD17000  FOB NINGBO
OPTIONAL EQUIPMENT    1)AUTO LOADER    2)DOUBLE WINDER    3)CORONA     4)AIR SHAFT     5)MANUAL MECHANICS SCREEN CHANGER   6)FULL AUTOMATIC WINDER   7)AUTOMATICALLY SUPPLY AIR
