ABC High Speed Plastic Bag Film Blowing Machine

Ruian Queensense Machine Co., Ltd.
  • Type：Multi-Layer Co-extrusion Film Blowing Machine
  • Raw Material：HDPE
  • Maximum Folding Width of Film：2000mm
  • Screw Diameter：65mm
  • Automation：Automatic
  • Computerized：Computerized

Base Info

  • Model NO.：QS-GS1200
  • Machine Weight：8T
  • Certification：CE, ISO9001:2008
  • Film Thickness：0.028-0.2mm
  • Max.Extrusion Output：120kg,H
  • Driving Motor：18.5-37kw
  • Winding Speed：5-50m,Min
  • Size：9.5*4.5*7.5m
  • Motor：18.5*3
  • Width：1200mm
  • Height：9.5*4.5*7.5
  • Speed：5-50m,Min
  • Die：280mm
  • Transport Package：Seaworthy
  • Specification：CE SGS
  • Trademark：QUEENSENSE
  • Origin：China
  • HS Code：847780000
  • Production Capacity：100PCS,Per Years

Description


Model
3SJ-G1000
3SJ-G12003SJ-G1500Diameter of screw55×2 60×160×2 65×165×2 70×1Length-diameter ratio28:1/30:128:1/30:128:1/30:1Speed of screw15-150r/min15-150r/min15-150r/minPower of main motor15Kw×2 18.5Kw×118.5Kw×2 22Kw×122Kw×2 30Kw×1Output of a single extruder50kg/h80kg/h100kg/hSpecification of die orifice150 φ200200 φ250×1250 300×1Film thickness0.01-0.10mm0.01-0.10mm0.01-0.10mmMax. lay-flat width of film1000mm1200mm1500mmTotal capacity of electric appliance76Kw88Kw102KwOverall dimensions:6600×4100×5000mm6800×4300×6000mm7000×4800×7500mmMachine weight4T5T6T
