Semi-Automatic 4 Cavity Drinking Water Bottle Plastic Bottle Molding Machine
Zhangjiagang Links-Machine Co., Ltd.- Type：Injection Blow Molding Machine
- Raw Material：PET
- Making Method of Parison：Stretch Blow
- Automation：Non-Automatic
- Computerized：Computerized
- Certification：CE, ISO9001:2008, QS, UL, GMP
Base Info
- Model NO.：LK-SA4
- Model：Lk-SA4
- Control System：Computerized
- Bottler Material：Pet
- Bottle Volume：100ml to 2000ml
- Machine Capacity：1800-2000 Bottles Per Hour
- Machine Installation Power：30kw
- Suitable for：Water Bottle, Beverage Bottle, Oil Bottle...Ect
- Workers Requests：1 Worker
- Certificate：SGS, ISO, Ce,..
- Weight：1200kgs
- Transport Package：Wooden Export Package
- Specification：ISO, SGS, CE
- Trademark：LINKS
- Origin：Zhangjiagang City, China
- HS Code：84774010
- Production Capacity：50,Month
Description
Electrical systemVoltage standard 380v/3PH/50Hz or special order Total power (full loaded) 18KW Container Max. container volume 2.5L Neck diameter range 15-45mm Max. container diameter 110mm Max. container height 370mm Auxiliary system High air compressor >1.2m3/3.0Mpax2 (0.5L) Dimension & weight (LxWxH) Blow molding machine 1.9x0.88x1.8m Pre-heater 1.9x0.66x1.6m Net weight 1.3T
| Item | Name | Brand name |
| 1 | Cylinder for stretching unit | FESTO |
| 2 | Pneumatic par for clamping unit | FESTO |
| 3 | Sealing cylinder | FESTO |
| 4 | Blowing Solenoid Valves | FESTO |
| 5 | Sealing solenoid valve | FESTO |
| 6 | Clamping Solenoid valve | AIRTAC |
| 7 | Stretching Solenoid valve | FESTO |
| 8 | PLC controller | TIANJING |
| 9 | Breaker | DELIXI |
| 10 | AC contactor | DELIXI |
| 11 | inverter | DELTA |
