Plastic Machinery

Home > Product > Film Blowing Machine

Single 1 Screw Double Dual 2 Die Head HDPE LDPE LLDPE Biodegradable Cornstarch PE Plastic ...

Wenzhou Zheke Machinery Co., Ltd.
  • Warranty：One Year
  • Type：PE Film Blowing Machine
  • Raw Material：HDPE
  • Maximum Folding Width of Film：600mm
  • Screw Diameter：50mm
  • Automation：Automatic

Base Info

  • Model NO.：ZK-G-500,600
  • Machine Weight：2t
  • Certification：CE, ISO9001:2008
  • Transport Package：Wooder
  • Trademark：ZheKe
  • Origin：China
  • HS Code：8477301000
  • Production Capacity：100sets,Year

Description

Basic Info.

Model NO. ZK-G-500/600 Machine Weight 2t Certification CE, ISO9001:2008 Transport Package Wooder Trademark ZheKe Origin China HS Code 8477301000 Production Capacity 100sets/Year

Product Description

Product Description

Single 1 Screw Double Dual 2 Die Head HDPE LDPE LLDPE Biodegradable Cornstarch PE Plastic Blown Film Blowing Extrusion Machine with 2 Winder
Use:
This machine set is used for blowing Low-density polyethylene (LDPE) and high- density polyethyene (HDPE) plastic film to make various vest bags and flat-rim bags which have been widely used for packing in the food industry, garment industry and textile industry, etc.

Features:
Both the cylinder and the screw of the extruder are made of high quality alloy steel through nitration and precision finishing with the best hardness and corrosion resistance., Scientifically designed, this machine set has two heads for one extruder with such advantages as increasing production capacity, saving energy, labour and workshop area, etc.
 Please contact the salesperson for the latest quotation and machine configurations.

We can design the machines according to your needs.
ModeRHT65/FM600*2RHT70/FM700*2RHT75/FM800*2
Diameter of screw65mm70mm75mm
Screw Ratio(L/D)30:130:130:1
Screw Speed10-110r/min10-110r/min10-110r/min
Max .Output50kg/h70kg/h90kg/h
Max. Folding Width of Film550mm*2650mm*2750mm*2
Single-sided Thickness of Film0.006-0.10mm0.006-0.10mm0.006-0.10mm
Power of Main Motor22kw30kw37kw
Total Power40kw55kw70kw
Weight of Machine3000kg3800kg4500kg
Overall Dimensions4800*2200*3800mm5000*2400*4000mm5200*2600*4200mm
