• Model NO.：CHSJ-S
• Machine Weight：10T
• Certification：CE, ISO9001:2008
• Main Motor Power (Kw)：Level 6
• Film Width(Folding Diameter)：300-1200
• Film Thickness(mm)：0.007-0.05
• Extrusion Capacity Kg/H：98-120kg
• Transport Package：Wooden-Box,Nude
• Specification：SGS
• Trademark：Chengheng
• Origin：China
• HS Code：8477309000
• Production Capacity：50sets,Year

Model
 S-40-45-40/900 S-50-65-50/1400
S-55-65-55/1600  S-65-75-65/1800Width of the film250-700mm   300-1200mm  500-1400mm 500-1600mmThickness of the film0.006-0.15mmThe max output115kg/h   135kg/h 155kg/h  175kg/h
According to different width,thickness of film, die size and raw material characteristics to changeRaw materialHDPE/LDPE/LDPEWeight3800kg   5200kg  9800kg  10200kgOverall dimension(L*W*H)m6.5*2.7*5  6.5*3*5.8 6.5*3.8*6.2   6.8*4*6.8Extruder unitDiameter of screwΦ40/45/40  Φ50/65/50   Φ55/65/55   Φ65/75/65
38CrMoALA  wearproof Alloy steel,five years guaranteeL/D ratio of screw30:1Rotation speed of screw10-120r/mBarrel FanZone 3 barrels install over-temperature fanGear box146#   173#  200#   225#
Extruder special hard gear reducer,tooth grinding teeth hardened, internal and external oil circulation systemMain motor15kw    22kw   30kw   37kw
100% Original three-phase variable frequency motor  Equipped with inverter controlDie head unitDie diameter
 60mm   80mm  120mm 250mm  360mm
With 40Cr steel forging finishing, eight feed trough runner,Uniform flow channel,blown plasticizing effectCool unitAir ring type
 LDPE double vents vacuum air ring
HDPESingle outlet air ringAir ring materialHigh quality Taiwan cast aluminum alloy air ringBellow power1.5kw  4kw   2.2kw   7.5kw   11kw
Shanghai production of high-pressure mute fanTraction unitrotation driver
 0.75KWair flotation reversing roller
 0.5kw×2movement way
 ±350°Width of take up roller900mm  1400mm   1600mm   1800mm Traction roller materialsilicone roll
NBR rollerTake up motor1.5kw  2.2kw  3.0kw
Installation of RV series reducer variable frequency motor inverter controlTake up speed100m/minconstant tension traction motor1.5kw10N.mwidth of traction roller700mm  900mm   1200mm   1400mm Lambdoidal boardWooden flannel wrapped
Aluminum roller guide  Gusset equipmentModular rack type
Independent Split Bubble stabilizing ringElectric aluminum roller guide
Manual wood floor Guide rollerAluminum guide roller (HV300-HV700) surface treatmentWinding unitWinding typeSurface friction rewinding, manually change the volumeDrive typeTorque motor equipped RV reducerFilm expanding rollerSmoothing rollElectric control cabinetlow-voltage is Universal electrical appliances, Delixi Electric, Taiwan's Yangming Electric, Huibang temperature control tableComputer control type7-inch touch screen + process control system
Automatic air supply device

Service
1.Free installation and ajustment.(for consumers purchase more than $100000 only)
2.One year free after-sales service(No charge for changing parts) and mechanical parts lifetime warranty.
3.We will offer you the professional answers about the relating machines in 24 hours.

Order step
    step1. Please let us know which product you like. the model and size, the offers will be sent to you within 24 hours.
     step2.  We make proforma invoice (PI) for you.
     step3. Please check and confirm the PI
     step4. Once we confirmed the order, please pay it soon.
     step5. After payment, all goods will be sent to you in the delivery time.
