• Model NO.：SP-510,580
• Weight：2500kg
• Power(W)：25kw
• Warranty：1 Year
• Control Method：Servo Motor
• Autotamatic：with Stacking System
• Transport Package：Wood Case
• Specification：CE
• Trademark：sinoplast
• Origin：Zhe Jiang, Wen Zhou
• HS Code：8477409000
• Production Capacity：100 Sets Per,Year

Basic Info.

Model NO. SP-510/580 Weight 2500kg Power(W) 25kw Warranty 1 Year Control Method Servo Motor Autotamatic with Stacking System Transport Package Wood Case Specification CE Trademark sinoplast Origin Zhe Jiang/ Wen Zhou HS Code 8477409000 Production Capacity 100 Sets Per/Year

Product Description

 Features:
1) It is used for forming not only BOPS but also HIPS/PS/PVC/PET plastic sheet into various of boxes, dishes, trays, bowls and lids.
2) It combines the material feeding, heating, shaping, and cutting into one process. The final products have been already cut one by one.
3) This machine adopts PLC program system, capability reliable, quality jarless, fault few. Servo motor drives the sheet transport system.
4) It has quickly production capacity, highly utilization ratios of plastic sheet, low air consumption and maintenance,
Beautiful final ready products, so it is new generation ideal package equipment.


Main Technical Parameters:

Model	SP-510/580
Max. Forming Area	510×580mm
Max. Forming Height	≤120mm
Sheet Thickness Range	0.15-1mm
Max. Dia. of Sheet Roll	710mm
Max. Cutting Length	5500mm
Suitable Material	OPS/HIPS/PVC/PET Sheet
Output	10-25cycles/min
Mould Platen Heating Power	15KW
Exhausted air volume	1200Liters/min
Water Consumption	10Liters/min (10-20ºC)
Power Source	380V,50Hz, Tri-phase
Machine Dimension	2.75×1.41×2.15(m)
Machine Weight	2.0T

Samples:
