PVC Ceiling Making Extruder Machine Made in China
Yuyao Guotai Rubber & Plastic Machinery Co., Ltd.- After-sales Service：Provided
- Warranty：Provided
- Type：Profile Extruder
- Plastic Processed：PP
- Product Type：Profile Extrusion Molding Machine
- Feeding Mode：One Feed
Base Info
- Model NO.：SJ65,25
- Assembly Structure：Integral Type Extruder
- Screw：Single-Screw
- Engagement System：Full Intermeshing
- Screw Channel Structure：Deep Screw
- Exhaust：Don′t Exhaust
- Automation：Automatic
- Computerized：Computerized
- Color：Customized
- Usage：Wide
- Motor Brand：China Famous Brand
- Frequency Inverter：Zoncn,ABB,
- Transport Package：Wood Pallet with Film Package
- Specification：Depends on model
- Trademark：GT
- Origin：Ningbo China
- HS Code：8477209000
- Production Capacity：300sets Per Year
Description
Mode
Screw Dia.
Length to
diameter
Rotational
Speed of screw
Height of center point
Capacity
Power
Drive motor
SJ-30/25CY
30mm
25:1
10-160r/min
1000mm
19.5kg/h
2.2kw,3kw
SJ-45/20
45mm
20:1
10-90r/min
1000mm
22.5kg/h
5.5kw
SJ-45/25CY
45mm
25:1
16-160r/min
1000mm
35kg/h
7.5kw,11kw
SJ-45/28CY
45mm
28:1
16-160r/min
1000mm
40kg/h
7.5kw,11kw
SJ-45/25HY
45mm
25:1
16-160r/min
1000mm
35kg/h
11kw
SJ-50/25HY
50mm
25:1
16-160r/min
1000mm
40kg/h
11kw,15kw
SJ-65/25HY
65mm
25:1
8-80r/min
1000mm
100kg/h
18.5kw
SJ-65/28CY
65mm
25:1
15-120r/min
1000mm
100kg/h
18.5kw,22kw
SJ-65/28HY
65mm
28:1
16-160r/min
1000mm
120kg/h
22kw,30kw
SJ-65/30CY
65mm
30:1
15-120r/min
1000mm
120kg/h
22kw,30kw,37kw
SJ-65/34CY
65mm
34:1
15-120r/min
1000mm
120kg/h
22kw,30kw,37kw
SJ-70/25HY
70mm
25:1
8-80r/min
1000mm
120kg/h
22kw
SJ-90/25HY
90mm
25:1
10-100r/min
1000mm
155kg/h
30kw,45kw,55kw
SJ-120/25HY
120mm
25:1
30-90r/min
1000mm
250kg/h
75kw
Our Services
If you are interested in our machines, please do not hesitate to contact us.Hope we can succeed in cooperation and establish a long term business relation.
FAQ
Q: Your company is a trading company or an industrial manufacture factory?
A: We are an industrial manufacture factory. We have independent technical team who focus on making machines, all the products are made by our technical team.
Q: What is the ability of your factory?
A: About 300 set per year.
Q: Do you have any other services about your products?
A: We have a lot of experience on making projects and specifications for our clients, also we have a fixed service system.
Q: How do you make the quotation for clients?
A: Please offer the following information, so we can give you price and our advice as manufacturer:
1. Type of pipe you want to produce.
2. Raw material and its types
If you can also send us photos of your samples, it would be highly appreciated.
Good comments from our overseas customers:
