• Computerized：Computerized
• Certification：ISO9001:2008, CE
• After-Sale Service：Eers Available to Service Machinery Overseas
• Color：Could Be Customized
• Model No：Lgwl300~3000
• Electric Grid：3p 220~440V 50 or 60Hz
• Material of Recycling Machines：Stainless Steel304
• Capacity：300-1000kg
• Container：20gp or 40hq Container
• Power Installed：120-290kw
• Electric Components：Schneider,Siemens
• Transport Package：Wooden Box Film
• Specification：different size depends on the capacity
• Trademark：LIANGUAN
• Origin：Zhangjiagang, China
• Production Capacity：10 Sets Per Month

ModelsCapacityTotal PowerWorkersLGWL300300kg/h95~150KW1~2LGWL500500kg/h180~250KW2~3LGWL10001000kg/h280~380KW2~3
Order flowing process:

Customer requirements →Scheme designed →confirmed by customers →order fixed →manufacturing →trial running in our factory →confirmed by customers →shipped →engineer available overseas →whole life after sales services

Q&A about recycling machines:

1. What is the function of the PE PP film washing recycling machines?
The PE PP film washing recycling machinery is used to recycle and process the PE agriculture film, PE bags, shopping bags, beverage bags, PP woven bags, and some other soft material etc…
2. Where does it collect the waste material for the PE PP film washing recycling machines?
The waste mater is gotten mainly from agriculture film, city rubbish and plant in bale package or separated. They are with much dirties, such as the earth, soil, sand, stone, glue, grass, oil, and some other dirties.
But by our many years experience to manufacture the washing line, we can promise to wash the material clean enough to take the washed material into the extruder to make granules. We have our special design to guarantee this point.
3. What are main parts of the PE PP film washing recycling machines?
The following is a standard structure of the PE PP film washing recycling machinery:
Belt conveyer--- crusher with water--- screw conveyer--- floating washer--- screw conveyer--- high speed friction washer--- high speed friction washer--- screw conveyer--- horizontal centrifugal dewatering machine (or squeezer)--- drying system 1--- transition hopper--- drying system 2--- storage silo--- operating panel
The up is a standard structure of the line, we can adjust it to remove some parts or add some parts due to the situation of the material or customers' requirements.
4. What capacity of the PE PP film washing recycling machinery?
300-1000kg/h for single washing line
5. What power of the PE PP film washing recycling machines?
150kw~480kw
6. How much water does it need of the PE PP film washing recycling machines?
3~8T per hour
7. How large space does it need for a PE PP film washing recycling machines?
100~400 square meters, the whole line could be installed by straight, "L" shape or "U" shape. We could design how to instal the machines due to the space of your factory.
8. What is the condition of the final products from the PE PP film washing recycling machines?
The size of final flakes will be 50~100mm, and final moisture level of film flakes will be lower than 5%.
The PP PE flakes can be taken directly to the granulating/pelletizing line to make granules/pellets.
9. What is material of the PE PP film washing recycling machines?
The parts contacted with water are made of stainless steel SUS 304 or customized.
10. What certifications do you have for the PE PP film washing recycling machines?
We have CE and ISO9001 certification for the entire PE PP film washing recycling machines.

Spare Parts
Customer's requirement is our first priority. We could provide you reliable, fast and professional service through telephone, network and on-site at any time. Normally, we send our customer one set of spare parts together with the machines when we deliver the product.
During the warranty, we provide new parts free of charge for you to replace, exclude the parts broken that caused by improper operation.
In our spare parts department, you will get professional technical advice, as well as the relevant information regarding all products and services.

Top Quality
LIANGUAN is a prestigious plastic recycling machinery manufacturer in China. Our customers have been enjoying a variety of advantages in particular in terms of the dedicated screw designed by our R&D team including good mixing, good dispersion, high productivity, and so on.

Implied Qarranty
LIANGUAN Machinery guarantees all new products and parts to the first owner-operator to be free from defects in material and workmanship for a period of 12 months from B/L date, under normal use and service.

After-sales service
1.Send engineers to install, test the machines and offer technology guidance and worker training at customers' factory.

2.Offer 12 months free maintenance and life long service. After the warranty period, spare parts will be provided at basic cost.

3.Build customers database. All machines are traceable.

4.Visit customers and make quality trace periodically and take customers' feedback into account during routine practices.

5.Speed up service and spare parts supply.
