• Model NO.：ZLRC-GRATING MACHINE6
• Size：Optional
• Work Principle：Hydraulic Lifting Principle
• Shaping Mode：Compression Mould
• After Sales Service：Engineers Available to Service
• Shipping：by Sea
• Visit Plant：at Any Time
• Transport Package：According to Customer′s Requirement
• Specification：customized
• Trademark：,
• Origin：Hebei, China (Mainland)
• HS Code：84778000
• Production Capacity：100 Sets ,Year
• Package size per unit product：4000.00cm * 1200.00cm * 1000.00cm
• Gross weight per unit product：4000.000kg

   Length×width
(mm)Thickness
(mm)Mesh  (mm)Open area
%Weight
(kg/piece)   1220×36602538×386955  1220×36603038×386965  1220×36603838×386983  1000×20002538×386925  1000×20003038×386929  1000×20003838×386937  1000×40002538×386950  1000×40003038×386958  1000×40003838×386974  1220×36605050×507296  1007×30071338×386919  1007×30074040×406458  1007×30072540×406436  1007×20072540×406424  1007×20074040×406439  1007×40072540×406448  1007×40074040×406477  1007×300725100×2566/5042/58  1220×36603819×1942110

 FRP grating machine

1.Ejector rod lifting device is two cylinder to parallel advance ,smooth ,no waveing.
2.Stripping plate and stripping beam adopt elasticity connection,go up and down is parallel and steady.
3.The module using delicate 45# steel,grinding,polishing and the surface is plating.It has antiseptic function,smooth and easy to demould.
4.Ejector rod can go up and down along with lifting device,easy to change and easy maintenance.
5.Ejector rod is made from steel parts grinding ,surface smooth,firmness and wear resistance.
6.Hydraulic station adopt hydraulic parts made by Sino-Japanese joint venture, it is long-life and durable
7.Mould temperature rise and drop are achieved by rectangular copper pipe, which have large contact area with template, temperature rise and drop fastly,and it can heat the mould top surface. In terms of the four borders of the mould,it is anti-corrosion and durable.Joint adopt stainless soft joint,joint destuffing is convenience,anti-corrosion and durable

Cautions:

Before use the new mold clean up oil stains and other dirt inside the mold.Before use the mold please check if the screws loose or not. If loose, please fasten in time.Keep the mold slide adequate oil, prohibit knocking the I beam steel with hammer. Spray the demoulding agent three times, spray the agent after curing the last spray.After producing 3-4 grating sheets spray the demolding agent to the mold. Produce after the agent drying. In the following production please spray the demolding agent periodically  according to the actual conditions.

Company Information

    ZLRC is a leading and professional manufacturer of fiberglass products for over 20 years.Specialize in producing fiberglass composite product by pultrusion, SMC and SMC molding, hand lay out and RTM technology. The annual production capacity is about 8,000tons. ZLRC with complete sets of professional equipment from fiberglass raw material manufacturing to after treatment, There are 10 advanced FRP pultrusion production lines, SMC production line, FRP hydraulic equipment from 100tons~3000tons, RTM production lines and test machine etc.With decades of experience and performance based on excellent technology and dedication to the top quality standards in manufacturing and customer satisfaction. ZLRC ensures our solutions are the most innovative and cost effective ones.
As an ISO accredited Company, ZLRC shows committed to quality, customer and a willingness to improve efficiency. The factory covers an area of 70,000m2, of production workshop 40000m2, there are 260 excellent staff, 13 senior technician, and 40 technician.
ZLRC  FRP has exported to South Asia, Middle Asia and Middle East, Europe, American and got high praise

Certificate







We are looking forward to cooperate with you! If you are interested, kindly feel free to contact us!
