China Manufacturer of Plastic Packaging Bottles ISBM Machine

Guangzhou JASU Precision Machinery Co., LTD.
  • Key Selling Points：High Efficient, Stable, Unique Modular Design
  • Company Type：Manufacturer, Direct Factory
  • Circle Time：10-12 Seconds
  • Working Mode：One Step, One Stage, Single Stage
  • Service Support：Serve on-Site, Response Via Both Voice and Videos
  • OEM/ODM Available：Yes

Base Info

  • Model NO.：ISB 800AN
  • Power Requirement：as Per Requests
  • Dimension (L*W*H)：4200*1750*3400 mm 4500*1950*3400 mm
  • Customer Design：Yes
  • Transport Package：Wooden Case
  • Specification：1-12 cavity for option
  • Trademark：JASU
  • Origin：Guangzhou
  • HS Code：8477401000
  • Production Capacity：120 Sets,Month

Description

ItemUnitMachine TypeISB 800N-3ISB 800AN-3ISB 1100N-3ISB 1100AN-3ISB 1100AN-100T-3Injection PartScrew Diametermm4050405050Screw L/D RatioL/D20.5:120.5:120.5:120.5:124:1Screw Speedr/min0-1900-1500-1900-1500-150Theoretical Injection Capacitycm3238481238481481Injection PressureMPa174176174176176Max. Hydraulic PressureKg/cm140140140140140The Actual Injection Quantityg(ps)225452225452452Oz81681616Screw Strokemm190245190245245Clamping PartBlow Clamping ForceKN8080150150150Clamp TonnageKN4004006006001000Wheel Diametermm800800110011001100Max. HeightPP, PET, PETG, Tritan, PS, PCmm200200200200200PC, PETG, Tritan, PS220220220220220Open Vertical Mode Tripmm570570570570600OthersMax. Pump PressureMPa1616161616Servo MotorKw2222222222Mode Opening & Mode Locking Use Ordinary Motor (Double Pump)Kw2222222222Electric PowerKw8.912.28.912.212.2Tank VolumeL420420420420420Dimension of Machinem4.2*1.75*3.44.2*1.75*3.44.5*1.95*3.44.5*1.95*3.44.5*1.95*3.4Machine WeightT5.568.599.5--Parameters are subject to change without prior notice.
--Providing PC, PET, PP, PS, PETG, TRITAN screw barrels according to customers' requirements.
Click to learn more
Q6: What about warranty and do the engineers available to overseas?
A6: One year warranty. During this period, if you need any support on installation, adjustment , operation or maintenance, our engineers can go abroad to fix for you.
Q7: Others?
A7: We will request the working voltage and power frequency at the buyer's side when he placing the order.
       Each order will be fulfilled as a turn key project of machine.
  1. Contact us to share more videos and details.
