Tongda Tdb-160d 100 Liter HDPE Plastic Drum Blue Barrel Blow Moulding Machine

Suzhou Tongda Machinery Co., Ltd.
  • Type：Extrusion Blow Molding Machine
  • Raw Material：HDPE
  • Making Method of Parison：Extrusion-Blow Molding
  • Automation：Automatic
  • Computerized：Computerized
  • Certification：CE, ISO9001:2008

Base Info

  • Model NO.：TDB-160D
  • Rotary Cylinder Brand：Festo
  • Station：Single
  • Suitable Bottle：120-160L
  • Key Words：Automatic Extrusion Blow Moulding Machine
  • Packing：Wooden
  • Use：Hollow Moulding
  • Parison Control：Moog
  • Max. Size of Mold：1000*1900
  • Hydraulic Valve：Yuken
  • Color：Blue
  • Transport Package：Packaged in Wooden Case
  • Specification：6.7*2.9*4.7
  • Trademark：TONGDA
  • Origin：China
  • HS Code：8477300000
  • Production Capacity：600sets,Year

Description

Overview Product Description

Product Details

Tongda Tdb-160d 100 Liter HDPE Plastic Drum Blue Barrel Blow Moulding MachineTongda Tdb-160d 100 Liter HDPE Plastic Drum Blue Barrel Blow Moulding Machine

Product Parameters Model UnitsTDB-160D
SpecificationStationSingle/DoubleSingleMax.product volumeL160Dry cyclepc/h120Output of HDPEkg/h300Weight of machinekg24000Size of machine(L*W*H)m6.7*2.9*4.7Die headMax.die diametermm700Die head heating zone-6Capacity of accumulator headL28Die head heating powerkw51.5Clamping UnitPlaten distancemm800~1800Clamping forcekn740Extruder UnitScrew diametremm100Screw length/diametre ratio-28Screw heating powerkw32No.of heating zone(screw)-5Power UnitHydraulic pump driving powerkw31.5+11Screw motor powerkw90Total powerkw216RemarksAir consumptionm³/min1.6Blow pressureMap0.6Cooling water pressureMap0.3Water consumptionL/min180Max size of mold(W*H)mm1000*1900Company Information


Tongda Tdb-160d 100 Liter HDPE Plastic Drum Blue Barrel Blow Moulding Machine
Shipping Packing


Tongda Tdb-160d 100 Liter HDPE Plastic Drum Blue Barrel Blow Moulding Machine

Why Choose Us


Tongda Tdb-160d 100 Liter HDPE Plastic Drum Blue Barrel Blow Moulding Machine
Service Marketing Network
FAQTONGDA sales consultant
1. We can provide comprehensive and professional Suggestions on equipment selection.
2. Energy consumption calculation and investment income analysis can be provided.
3. Provide tailor-made CAD drawings of workshop layout and product optimization Suggestions.
4. Extrusion plastic bottle blow molding machine has remote maintenance function

Advantages of TONGDA tech teams
1. 600 sets of customized requirements per year enable us to have rich experience across multiple industries.
2. Customize equipment models according to customer product characteristics.
3. Project responsibility system, closed-loop team cooperation between the design team and the process team, adjustment of the team, and joint creation of equipment that users are satisfied with.
4. Engineers can study abroad or participate in technical function training of the industry to master the latest information and technical trends of the industry.
5. Undertake a number of large projects, and has a group of senior technical personnel composed of the construction team, can build cable bridge, installation of a complete set of equipment.

Advantages of TONGDA after-sales team
1. Lifetime free service for the machine.
2. Quick response all day long.
3. Set up domestic service team and international service team.
4. Technicians also master the debugging and maintenance of auxiliary equipment.
5. A free 2-day training course will be provided to customers every year.
6. Special processing equipment to produce after-sales accessories to ensure rapid response to user needs.

Q: how big is your company?
A: our company has 270 employees and A building area of 53,330 square meters. We own land and factories.The company has a
registered capital of us $2 million and a long-term business license since 1998.

Q: how long is the warranty on your equipment?
A: we offer A one-year free warranty and A lifetime after-sales service.
