• Model NO.：YCQ-5L-1
• Bottle Material：Pet
• Driven Type：Pneumatic
• Voltage：According to Customer Request
• Cavity：1
• Theory Output：1200-1500PCS,Hr
• Max. Volume：5L
• All Electric Machine Installation：35kw
• Size of The Machine：2.4X1.5X1.7 (M)
• Weight of The Machine：2000kg
• Transport Package：Wooden Package or as Customer′s Request
• Specification：CE ISO SGS
• Trademark：eceng
• Origin：Zhangjiagang Jiangsu
• HS Code：8477300000
• Production Capacity：6-8 Per Month


Bottle type specification
 cavity1theory output (PCS/HR)1200-1500 Max. volume (L)5LBottle mouth maximum overall diameter (mm)150mmBottle biggest diameter180mmBottle maximum height400mm
Power specifications
 Light tube quantity32pcsLight tube power1kwMaximum heating power32kwAll electric machine installation35kwActual consumption17.5kw
Air pressure specification
 Work pressure7-9kg/cm2Low-pressure gas consumption1200Ltr/minBlow bottle pressure25-35kg/cm2Higher -pressure gas consumption2000-2500 Ltr/min
Frozen water specification
 Work pressure5-6 kg/cm2Temperature range10Consumption4000kcal/hrFrozen water flow30Ltr/minMachine specificationSize of the machine2.4x1.5x1.7 (m)Weight of the machine2ton

After-sales service
1.we will provide the bill of load on time to make sure you can get the machine quickly
2.when you finish the Preparation conditions ,our engineer will go to your factory to install the machine ,and give you the operating manual ,and train your employee until they can operate the machine well.
3.we provide one year warranty with spare parts free.
The sample service
1.we can send you the video of the running machine.
2.you are welcome to come to visit our company,and see the machine running in our factory,we can pick you up from the station near our city.
3.If we get  the permission of the customer who has brought the machines from us ,we can tell you their contact imformation,you can go to vist their factory.
Customized service
1.we can design the machines according your requirements(materil ,power,filling type,the kinds of the bottles,and so on).
2.at the same time we will give you our professional suggestion,as you know,we have been in this industry for many years.


Transportation:
   It is located in the beautiful port city of Zhangjiagang with convenient traffic; it's about 150 km away from Shanghai.
Products:
   PVC/HDPE/PP-R pipe extrusion line, PVC & WPC profile extruding line and plastic sheet production lines with the relative auxiliary machine, PE film/ PET bottles recycling line and pelletizing lines.
Market:
   Our products have been exported to Middle East, Southeast Asia, South America and Europe etc. We received the universal confirmation and trust from our customers except of the precious experience.
Idea:
   Abide by the logos of "Sincerity, Development, innovation, Win-Win" constantly, we are honorable to cooperate with friends at home and abroad by providing the high quality products, technology and service!
