• Model NO.：TSD-30002
• Type：1- 3 Layers
• Hydarulic System：Yuken
• Servo System：Rexroth, Germany or as Request
• Transport Package：Wooden Box
• Specification：3000 Liters
• Trademark：TSD
• Origin：China
• Production Capacity：60, Year

Basic Info.

Model NO. TSD-30002 Type 1- 3 Layers Hydarulic System Yuken Servo System Rexroth, Germany or as Request Transport Package Wooden Box Specification 3000 Liters Trademark TSD Origin China Production Capacity 60/ Year

Product Description

3000L multi layers HDPE hollow water tanks blow moulding machine.
available to blow Max. 5000L plastic products, 1- 3 layers
can blow plastic tanks, chemical drums, tray, pallet etc in horizonal/ vertical type


MOQ: 1 Set
Delivery time: 120 days
Including 3 sets of moulds, 1000L,2000L & 3000L

Configuration:


Computer system:  Mitsubishi PLC, touch-screen, all operations can be done by touch-screen.
Hydraulic System: Dual-ratio pressure control, the hydraulic parts from famous brands to guarantee the quality.
Plasticizing System: High efficiency BM-type screw, ensure the even plasticizing.
Rate-control system: variable frequency design, low noise, wear well.
Moulds-moving system: Line lead rail, high-precision, small resistance.
Needle-blow shelf: Angle-rule type shelf, fixingstableness.


Technical characteristic:

Open-close-moving moulds system: Ball type line rail to realize open-close-move operation separately.
Material-in accmulator head: 38CrMoAlA steel, nitriding process, high intensity, high fineness.
Convenient mould-change: Hydraulic system controls die head and above machine body go up and down coinstantaneously, and front and back moving freely to leave space for assembling other moulds.
Shape-base control system: MOOG system, multipoint curve control, high- precise.

For more techinical info. pls contact us.
