• Trademark：OULIN
• Model NO.：100mm
• Origin：China
• HS Code：84779000
• Production Capacity：300-500 Sets Per Year

Basic Info.

Model NO. 100mm Trademark OULIN Origin China HS Code 84779000 Production Capacity 300-500 Sets Per Year

Product Description

Detail Information For 100mm Bimetal Screw+ Bimetal Barrel for Recycled HDPE Sheet:

Application: for recycled HDPE sheet extrusion.

Customer's Requirement: good abrasive resistance

Screw's quality: bimetallic quality, 38CrMoAlA as base steel, 30% tungsten carbide powder will be added in to alloy layer.

Barrel's quality:  OULIN-AR01 bimetal barrel


Detail Information For All Single Screw and barrel for Extrusion:

Main application: be used in extrusion for film, pipe, recycling, pelleting, sheet, profiles, rod and etc.

Specification:
Diameter: Ø20mm-Ø500mm
L/D ratio: 15-53

Base material :
SKD61
42CrMo
38CrMoAlA(JIS SACM645) from BAOSTEEL company.

Heat treatment:
Advance hardening and tempering
Nitriding treatment
Mid-frequency hardening

Technical Parameters:
Nitriding depth: 0.50mm-0.80mm
Nitriding hardness: HRC56-58
Surface roughness: Ra 0.4
Screw straightness: 0.015mm
Hard chrome layer hardness: HRC58-60
Hard chrome layer thickness: 0.025-0.1mm
Alloy layer depth: 2mm-3mm
Alloy layer hardness: HRC56-64


OULIN SCREW:  YOUR LOYAL PARTNER FOR SCREW AND BARREL
