• Model NO.：SS-RW03
• Spindle Number：1
• Wire Diameter：0.02~0.5mm
• Max. Speed：300 ~8570rpm
• Memory：999 Steps
• Power Source：AC220V,110V + 10%, 50,60 Hz
• Transport Package：Customs Approved Wood Box
• Specification：SS-RW03
• Trademark：SANSHINE
• Origin：China
• HS Code：8479811000
• Production Capacity：10000,Set

The programable semiautomatic plastic string rewinding machine (SS-RW03) is a digital coil rewinding machine. This rewinder adopts digital controller. It's an accurately and reliability digital rewinding machine. This rewinding machine is used for rewinding the PVC or Nylon wire to be one small coil from the big spool within a lot of wire. This string wire rewinding machine is called manually PVC wire rewinding machine and plastic wire coil rewinding machine also. It is a very economical rewinding machine.

Features :

1. Precise count turns of winding by precise photo-electricity sensor.

2. Programmable winding direction, winding turns, winding speed, pre-stop and pre-start speed. Programmable many steps for many different windings coil.

3. Scientific fast type winding fixture for winding and unload finished coil easy.

4. Memory capacity accommodates 99 sequences of parameters with off-power memory retention.

5. More convenience through using foot-switch.

Specification :

Wire size : φ 0.02~0.5mm

Winding speed : 300 ~8570rpm

Winding motor : DC brushless motor

Memory capacity : 999 steps

Power source : AC220V/110V±10%, 50/60 Hz.

Brake way : Use the reverse electromotive force of motor.
