600mm ABA 45*45 Mini film Blowing Machine
WENZHOU HUACHU MACHINERY CO., LTD.- Type：Multi-Layer Co-extrusion Film Blowing Machine
- Raw Material：HDPE
- Maximum Folding Width of Film：800mm
- Screw Diameter：45mm
- Automation：Automatic
- Computerized：Computerized
Base Info
- Model NO.：HDABA45X2X1000
- Trademark：000
- Origin：Zhejiang
- HS Code：8477301000
- Production Capacity：200
Description
FEATURESUITABLE MATERIAL HDPE, LDPE,LLDPE LAYER NUMBER 3-ABA FILM THICKNESS HD: 0.01-0.06MM, LD: 0.03-0.08MM MAX OUTPUT 100KG/H MAX FILM WIDTH 900MM EXTRUSION UNIT SCREW DIAMETER Φ45X2 SCREW L/D RATIO 30/1 SCREW MATERIAL BIMETALLIC BARREL MATERIAL BIMETALLIC BARREL THERMO CONTROL 3X2 BARREL COOLING FAN 200WX3X2 SCREEN CHANGER STANDARD DRIVING MOTOR 18KWX2 SIEMENS GEARBOX #146 EXTRUSION DIE UNIT DIE HDABAΦ60/80 DIE TYPE FIXED DIE THEROMO CONTROL 2 AIR RING DUAL LIP FLANGE THERMO CONTROL 2 AIR BLOWER 5.5KW, CHUANFAN TAIWAN TAKE UP UNIT TAKE UP TYPE FIXED BUBBLE CAGE MATERIAL WOODEN TOP NIP MATERIAL WOODEN TAKE UP ROLL MATERIAL HIGH TEMP RUBBER TAKE-UP ROLLER LENGTH 1000MM GUSSET INCLUDED TAKE-UP MOTOR 1.5KW GEAR MOTOR TAKE-UP SPEED 10-80M/MIN PINCH PATTERN PNEUMATIC WINDING UNIT WINDING TYPE SINGLE MANUAL WINDER WINDING ROLLER LENGTH 1000MM WINDING SHAFT STOPPER SHAFTX2 BANANA ROLLER WITH MAX DIA.OF WINDED ROLL 800MM WINDING MOTOR TORQUE MOTOR SPEED CONTROL SPEED CONTROLLER CONTROL PANEL HEATING SYSTEM ACR+PID (ENERGY SAVING) TEMP. CONTROLLER FOTEK (TAIWAN) WORKING VOLTAGE 380V,50HZ INVERTER BRAND DELTA
