Horizontal Type Plastic Dewatering Machine
GUANGZHOU PANYU QIANGYE MACHINERY CO., LTD.- Material Processed:Plastic Flakes
- Plastic Type:PE
- Screw:Single-Screw
- Automation:Automation
- Computerized:Non-Computerized
- Certification:CE
Base Info
- Model NO.:Model-600
- Transport Package:Plastic
- Specification:600mm
- Trademark:Qiangye
- Origin:Guangzhou China
- HS Code:8421191000
- Production Capacity:20sets,Month
Description
Basic Info.
Model NO. Model-600 Transport Package Plastic Specification 600mm Trademark Qiangye Origin Guangzhou China HS Code 8421191000 Production Capacity 20sets/MonthProduct Description
Horizontal type plastic pe film dewatering machineSpecial Features:
1.Especially suitable for all kinds of plastic films, also suitable for dewatering and drying granules and flakes materials.
2.The parts direct contacting with the raw material made of stainless steel material and can be customized as customer requests.
3.Can be used separately or used in production line for continuous process.Capacity is 500-1000kg/h.
4.Good adaptability and long service life.
5.Using electrical control security design to ensure the safety of operators.
6.Dewatering rate can reach up to 98%.
7.We can design the machine according to the customer's requirements.
Model | Capacity KGS/hr | Rotor Size (Dianmeter*Length mm) | Motor Power (KW) | Rotor Speed (r/min.) | Machine Size (L*W*H mm) | Weight (KGS) |
HD-600 | Appr.1000 to 1500 | Φ600*1200 | 22/30 | 1450 | 2560*1000*2000 | 2300 |
HD-800 | Appr.2000 to 2500 | Φ800*1800 | 45 | 1450 | 2815*1960*2320 | 3800 |
