Large Wood Pulverizer Shredder
Changshu Shi Shouyu Machinery Co., Ltd.- After-sales Service：One Year Warranty, Life-Long Maintenance!
- Type：Shredder for Wood
- Raw Material：Wood, Plastic, Metal, Glass, Waste.
- Structure：Shredding
- Knife Classification：Piece Knife Crusher
- Knife Roll：Solid Knife Roller
Base Info
- Model NO.：SR600-SR2500
- Automation：Automatic
- Computerized：Computerized
- Certification：CE, ISO9001:2008
- External Dimensions(mm)：4100X3300X2700mm
- Transport Package：Wooden Package,Film Package,Steel Frames Package,C
- Specification：CE,ISO9001,SGS
- Trademark：SOYU
- Origin：China
- HS Code：84778000
- Production Capacity：500sets,Year
Description
Model
SR600
SR750
SR900
SR1100
Main shaft rev(rpm)
73
73
73
73
Pushing chamber route(mm)
500
820
820
820
Rotation diameter (mm)
φ220
φ400
φ400
φ400
Number of Rotor blades (pcs)
23
33
39
49
Number of Stator blades (pcs)
4
6
6
8
Discharge height(mm)
500
600
760
760
Screen hole diameter (mm)
40
40
40
40
Motor power(kw)
18.5
37
37~45
55~75
Hydraulic power(kw)
1.5
2.2
2.2
5.5
Cutting chamber (WXL)(mm)
600x510
830x768
900x830
1130x830
Dimension(LXWXH)(mm)
1850x1300x1700
2700X1500X2000
2700x1950x2150
2700x2300x2150
Weight(kg)
Approx 1600
Approx 3300
Approx 4100
Approx 4700
Model
SR1400
SR1600
SR2100
SR2500
Main shaft rev(rpm)
73
73
73
73
Pushing chamber route(mm)
820
1000
1000
1000
Rotation diameter (mm)
φ400
φ480
φ480
φ480
Number of Rotor knifes (pcs)
60
70
92
112
94
122
150
Number of Stator blades ( (pcs)
10
12
16
20
Discharge height(mm)
760
950
950
950
Screen hole diameter (mm)
40
40
40
40
Motor power(kw)
75~90
2X45~2X55
2X55~2X75
2X75~2X90
Hydraulic power(kw)
5.5
7.5
7.5
7.5
Cutting chamber (WXL)(mm)
1360x830
1590x1000
2055x1000
2515x1000
Dimension(LXWXH)(mm)
2700x2600x2150
4100x3300x2700
4600x3300x2700
4900x3300x2700
Weight(kg)
Approx 5600
Approx 8200
Approx 10500
Approx 12500
