Mini Single Screw Film Blowing Machine

WENZHOU HUACHU MACHINERY CO., LTD.

Type：High and Low Pressure Film Blowing Machine
Raw Material：LLDPE
Maximum Folding Width of Film：600mm
Screw Diameter：45mm
Automation：Automatic
Computerized：Computerized

Base Info

Model NO.：YN-LM45B-700
Machine Weight：4T
Transport Package：Wooden Packing
Specification：8CBM
Trademark：000
Origin：Zhejiang
HS Code：8477301000
Production Capacity：240

Description

SACM-645 STEEL WITH
HARDENED & NITROGEN TREATMENTCYLINDER MATERIALCYLINDER COOLING1/4 HP x3DRIVING MOTOR20 HPHEATER CAPACITY14 KWDIES (mm)Φ120CONTROL PANEL TYPEATTACHED TYPE SWITCH BOARDTEMPERATURE CONTROL4 POINTSCOOLING TYPEAIR COOLING TYPEAIR BLOWER2 HP + INVERTERTAKE-UP TYPEFIXEDPINCH ROLLER (mm)Φ165 x700 LTAKE-UP MOTOR2 HP + INVERTERTAKE-UP SPEED (m/min)6-60WINDING UNIT TYPEATTACHED MANUAL WINDEREFFECTIVE WIDTH600mmFILM WIND-UP ROLL DIA.Φ700 mmWINDING MOTOR2 HP + INVERTERDIMENSION(LxWxH)(m)2.5x1.8x3.5OPTIONAL DEVICESAUTO HOPPER LOADER,
ROTATY DIE DEVICE,
EMBOSSING ROLLER, AIR SHAFT,
CORONA SURFACE TREATER

Mini Single Screw Film Blowing Machine

Mini Single Screw Film Blowing Machine

Mini Single Screw Film Blowing Machine

Mini Single Screw Film Blowing Machine
