16mm-63mm HDPE Gas Supply Water Supply Single Layer Pipe Extrusion Machine
QINGDAO TRUSTY PLASTIC MACHINERY CO., LTD.- Warranty：14 Moths
- Product Type：PE Pipe
- Screw No.：Single-screw
- Automation：Automatic
- Computerized：Computerized
- Certification：CE, ISO9001:2008
Base Info
- Model NO.：SJ-65
- Customized：Customized
- Condition：New
- After-sales Service：Oversea Installation and Debugging
- Control System：Siemens PLC System
- Temperature-Controller：Omron
- Breaker：Siemens
- Inverter：ABB
- Contactor：Siemens
- Transport Package：Wooden Packing
- Specification：16-63mm
- Trademark：Trusty
- Origin：Qingdao
- HS Code：84772090
- Production Capacity：100 Pieces,Year
Description
2.Machine List
| Name | Quantity(set) |
| Automatic drying feeder | 1 |
| Single screw extruder | 1 |
| Marker line extruder | 1 |
| Extruding mould | 1 |
| Shaper | 1 |
| Vacuum tank | 1 |
| Spray box | 1 |
| Haul off with caterpillar | 1 |
| Computer printer | 1 |
| Chipless cutter | 1 |
| Roll over table | 1 |
| Crusher | 1 |
3.Production Process
Feed→Extrude→Shape→Spray→Haul off→Print→Cut→Stack the material→Crush
4.Technical Parameter
| Model | SJ-65 |
| Total installation power(kw) | 90 |
| Transformer (kw) | 100 |
| Actual electricity consumption(kw) | 60 |
| Capacity (kgh) | 120-180 |
| Line speed (mmin) | 5-10 |
| Pipe Diameter(mm) | 20-63 |
| Motor Power(kw) | 37 |
New and old customers are willing to visit our company to guide and jointly develop new requirements, new standards, new technologies and new processes in this industry.We are in unremitting efforts to work with you to create a brilliant tomorrow.
6.After sales service
(1)After the machines are finished, the seller will test all machines before shipment. If the buyer can not come to test the machine, we will test the machines and send the sample to buyer.
(2)After shipment, the seller will send one or two technicians to the buyer' s factory to help the buyer install the machine and train workers for buyer.
(3)We will supply all electricity drawing, machine installation drawing.
(4)When make shipment, we will put some spare electricity parts for free, like the barrel hearers, thermcouples, breakers, relays, and other items which is easier broken.
