Plastic Machinery

Programmable PLC Control Fast Food Box Thermoforming Machine

Zhejiang Hongyin Machinery Co., Ltd.
  • After-sales Service:Video Technical Support, Free Spare Parts
  • Warranty:1 Year
  • Certification:CE, ISO
  • Column number:Four Column
  • Molding Method:Pressing
  • Automatic Grade:Automatic

Base Info

  • Model NO.:HY-51,62
  • Max. Forming Area:510*620mm
  • Max. Forming Depth:100mm
  • Thickness of Sheet:0.1-1.0mm
  • Power Supply:AC 380V, 50,60Hz
  • Raw Material:BOPS, PVC, Pet, HIPS, PS
  • Application:Container, Box, Lid, Tray
  • Procedure:Feeding-Heating-Forming-Cutting
  • Driven Type:Mechanical, Electrical, Pneumatic
  • Plastic Type:Plastic Packing
  • Weight:3500kg
  • Transport Package:Wooden Case
  • Specification:510*620
  • Trademark:hy
  • Origin:China
  • HS Code:8477800000
  • Production Capacity:20sets,Year

Description

The parameter of stacker1. Stacking area: 510×620mm 2. Suitable depth: 100mm 3. Air consumption: 200 Liters/min4. Power: 1.8kw5.Weight: 300kg6. Dimensions (L ×W×H): 2530×2500×2100 mmProgrammable PLC Control Fast Food Box Thermoforming MachineProgrammable PLC Control Fast Food Box Thermoforming MachineProgrammable PLC Control Fast Food Box Thermoforming MachineProgrammable PLC Control Fast Food Box Thermoforming MachineProgrammable PLC Control Fast Food Box Thermoforming MachineProgrammable PLC Control Fast Food Box Thermoforming MachineProgrammable PLC Control Fast Food Box Thermoforming Machine
About Ruian Hongyin Machinery Co., Ltd Service.

Purchase Service:

Wenzhou Hongyin Company has a specialized and efficient working team. If you are new to the printing and packing area, Some samples of your products that could be shown to us will be appreciated, we will give you a specialized suggestion of whole work.

Installation Service:
We could assign 1 technician to coordinate installation, commissioning, and training, the cost for the return flight and suitable accommodation will be charged, and the allowance is USD 100-150 per day.


Warranty Service:
12 months limited warranty.
Starting from the date of machine arrival buyer's place excluding wear parts.
Shipping costs for easy broken parts to be replaced during the warranty period have to be borne by the customer.


If you are interested in our machine, please feel free and contact me.
Ms. Lynn
