• Computerized：Non-Computerized
• Certification：ISO9001:2008
• Name：Heavy Duty Scrap Metal Shredder
• Use：Scrap Metal Shredder
• Shaft Design：Double
• Power：74-320kw
• Plastic Type：Metal or Mixed
• Voltage：380V,50Hz,3phase or Customize
• Dimension(L*W*H)：See Technical Parameter
• Weight：7000-36500kg
• Capacity：6-35t,H
• Finished Chips Size：Related with Cutting Head Number
• Transport Package：Standard Packing
• Specification：metal shredder
• Trademark：Kowloon
• Origin：China

Basic Info.

Computerized Non-Computerized Certification ISO9001:2008 Name Heavy Duty Scrap Metal Shredder Use Scrap Metal Shredder Shaft Design Double Power 74-320kw Plastic Type Metal or Mixed Voltage 380V/50Hz/3phase or Customize Dimension(L*W*H) See Technical Parameter Weight 7000-36500kg Capacity 6-35t/H Finished Chips Size Related with Cutting Head Number Transport Package Standard Packing Specification metal shredder Trademark Kowloon Origin China

Product Description

professional industry shredder Metal aluminum Shredder

Discription:

Twin-shaft shredder also named shearing machine, by cutting, tearing and extruting to reduce the materials' size, widely used in area of waste plastic, waste rubber, metal, wood, crop straw, automobile recycling…etc, this is a quality and reliable equipment in recycling business.

Technical parameters:

Model	JLSS400	JLSS600	JLSS1000	JLSS1200	JLSS1500	JLSS1900	JLSS2600
Main power	4-7.5kw*1	4-15kw*2	4-30kw*2	4-37 kw*2	4-45kw*2	4-90 kw*2	4-160kw*2
shaft rotary speed	18-20rpm	18-20rpm	18-20rpm	18-20 rpm	14-16 rpm	14-16 rpm	16-18 rpm
Working capacity	1-2t.h	2-5t/h	5-10 t/h	6-15 t/h	8-18 t/h	10-25 t/h	25-60 t/h
Weight	1000kg	3000kg	5000 kg	6000 kg	12000 kg	15000 kg	36000 kg
Conveyor motor power	None	None	None	None	4-3kw	4-3kw	4-3kw
cutter specifications	24pcs*φ170	20pcs*φ400	34 pcs*φ400	42 pcs*φ400	46 pcs*φ550	50 pcs*φ600	40 pcs*φ720
Finished ships size	1-10cm	2-10cm	3-10cm	3-10cm	3-10cm	3-10cm	3-10cm
Feeding tank size	0.7x0.65m	0.82×0.9m	1.2×1m	1.4×1m	2×2m	2.3×2m	2.5×1.4m
Dimension	1.45x1.1x1.6m	2.6×2×1.9m	3×2×1.9m	3.2×2×1.9m	4×1.7×2.4m	8×2.5×2.4m	8.2×4×4.3m

Features:

-Use thick and heavy duty knives, high shredding efficiency.

-Moving blade and dead blade both made of alloy steel, can resistance to high torque, high strength and very durable.

-Entire frame made up by thick steel board, low maintainance, economy and durability.




KOWLOON was established since 1986, located in Zhengzhou city, which city of industrial hub of China, 30years experience on manufacturing of:

Wood processing machinery: wood pellet production line, wood shredder, wood drum chipper, wood sawdust machine, wood powder machine, rotary dryer and air flow drying machine, wood debarking machine.

Waste tire recycling machinery: tire recycling plant, industrial two shaft shredder, tire roller mill multi-purpose rasper, rubber granulator, rubber powder machine, tire cutting machine, tire steel debeader, and fiber separate machine.

By now, KOWLOON machines were exported to more than 30 countries and share market in worldwide, owns oversea distributors and after-sale service center and now still growing continuously.

FAQ

YOU MIGHT INSTERESTED IN FOLLOWING QUESTIONS__

1. Are you manufacturer or trading company?

    Kowloon machines were exported by trading companies to more than 30countries, but KOWLOON is international trading department of factory only, supplying full technical support and solutions, timely and professional service, Kowloon people always effort on quality, honest, win-win business for every client.

 2. How do you assistant to install the machine on worksite?

     We are experienced on turn-key project, engineer and technicians will assistant client on construction, installation, commissioning.

 3. How can i get spare parts for replacement in other countries?

   Wearing parts like blades, it is necessary to buy with machine, other parts in stock could be delivery out by express if urgent or by sea within 5days.

 4. Can I use mark machine with different LOGO and color?

      Yes, please confirm details with sales.

 5. Can your customers test the machines?

      Before buying and after production before leaving factory, we test machine you interested or paid with specified materials, free of charge.
