HDPE Pipe Production Line/PVC Pipe Production Line/HDPE Pipe Extrusion Line/HDPE Pipe ...
ZHANGJIAGANG QING CHEN YU MACHINERY CO., LTD.- Product Type：PE Pipe
- Screw No.：Single-screw
- Automation：Automatic
- Computerized：Computerized
- Certification：CE
- HDPE Pipe Production Line：63-1200mm
Base Info
- Model NO.：xjg
- Transport Package：Wooden
- Specification：ISO,CE
- Trademark：XJG
- Origin：China
- HS Code：8477800000
- Production Capacity：Uncertain
Description
Basic Info.
Model NO. xjg Transport Package Wooden Specification ISO/CE Trademark XJG Origin China HS Code 8477800000 Production Capacity UncertainProduct Description
Main technical charateristics:Based on 20 years of plastic extrusion machinery development and design experience, my company combined the advanced technology and digestion to prompt this HDPE water supply pipe and gas pipe production line. Its unique structure design and high efficiency performance makes it fast accepted by the pipe factories.
The extrusion line consists of high efficiency single screw extruder, vacuum calibration, spraying water cooling tank,multi-claw haul-off machine, planetary cutting machine,pipe stacker and trolley.
It adopts PLC control system and HMI for whole extrusion line, synchronization function realized,as well as
the winding machine.It helps the group machine.
| Type | Pipe Size (mm) | Extruder Model | Max. Speed (m/min) | Max.Extrusion Capacity (kg/h) | Total Power (kw) | Total Length (m) |
| XJG-800 | 560~800 | SJ120/33 | 0.5~0.8 | 900 | 580 | 75 |
| XJG -1200 | 630~1200 | SJ150/33 | 0.4~0.6 | 1100 | 800 | 85 |
| XJG -1600 | 800~1600 | SJ90/33*2 | 0.3~0.4 | 1100 | 640 | 95 |
| XJG -2000 | 1200~2000 | SJ120/33*2 | 0.2~0.3 | 1800 | 1000 | 110 |
