Plastic Moulding Machine with Servo Motor for Traffic Barrier
Zhangjiagang Dawson Machine Co., Ltd.- Type：Extrusion Blow Molding Machine
- Raw Material：HDPE
- Making Method of Parison：Extrusion-Blow Molding
- Automation：Automatic
- Computerized：Computerized
- Certification：CE
Base Info
- Model NO.：ABLD120
- Output Capacities：as Per Samples
- Screw Diameter：120mm
- Screw L/D Ratio：28 L,D
- Screw Drive Power：75kw
- Screw Heating Capacity：30 Kw
- No.of Heating Zone：5 Zones
- Output of HDPE：240 Kg,H
- Oil Pump Drive Power：45 Kw
- Clamping Force：800 Kn
- Delivery Time：75days
- Transport Package：Film Packing
- Specification：ABLD120
- Trademark：Dawson
- Origin：Zhangjiagang, Jiangsu, China
- HS Code：8477301000
- Production Capacity：as Per Samples
Description
Basic Info.
Model NO. ABLD120 Output Capacities as Per Samples Screw Diameter 120mm Screw L/D Ratio 28 L/D Screw Drive Power 75kw Screw Heating Capacity 30 Kw No.of Heating Zone 5 Zones Output of HDPE 240 Kg/H Oil Pump Drive Power 45 Kw Clamping Force 800 Kn Delivery Time 75days Transport Package Film Packing Specification ABLD120 Trademark Dawson Origin Zhangjiagang, Jiangsu, China HS Code 8477301000 Production Capacity as Per SamplesProduct Description
ABLD120 High-Speed Automatic Roadblock Blowing Machine
was specially designed for making plastic water tanks, plastic cans, lubricant oil bottles, plastic drums, plastic toys and other plastic containers not over 250L.
The features of this Roadblock making machine:
(1)It is suitable for producing PE, HDPE, PP, PVC so on, plastic containers and bottles in all shapes are available, the max. Product volume is up to 250L.
(2)Single station single die head design, very easy to operate and maintenance.
(3)Most components of the blow moulding machine are from famous world brand.
(4)Fully automatic process with low power consumption, high efficiency, quick and safe operation, easy for maintenance.
(5)Accumulation die head, MOOG parison controller equipped.
(6)Bottom blow technology make the product perfect.
(7)Auto lubricant system controlled by PLC.
| Max. Product volume | 250 liters |
Output capacities | As per samples |
Screw diameter | 120mm |
Screw L/D ratio | 28 L/D |
Screw drive power | 75 KW |
Screw heating capacity | 30 KW |
No.of heating zone | 5 zones |
Output of HDPE | 240 KG/H |
Oil pump drive power | 45 KW |
Clamping force | 800 KN |
Max.size of mold | 1000X1500mm |
Mold stroke | 600-1500mm |
Max.die diameter | 520mm |
Die heating power | 12 KW |
Die heating segments | 5 zones |
Blowing pressure | 0.8mpa |
Air volume | 1.6 M³/MIN |
Cooling water pressure | 0.3mpa |
Water consumption | 180 L/MIN |
