Bimetal Screw and Barrel for High Speed Extrusion

ZHOUSHAN JINTANG OULIN MACHINERY CO., LTD.
  • After-sales Service:If Has Quality Defects, a New One Will Be Made.
  • Warranty:180 Days
  • Standard:DIN, JIS
  • Technics:Cutting, Heat Treatment, Pta Welding, Casting
  • Feature:Long Working Life
  • Material:Alloy Steel

Base Info

  • Model NO.:20mm-500mm
  • Transport Package:Plywood Case
  • Specification:20mm-500mm
  • Trademark:OULIN
  • Origin:China
  • HS Code:84779000
  • Production Capacity:300-500 Sets Per Year

Description

Basic Info.

Model NO. 20mm-500mm Transport Package Plywood Case Specification 20mm-500mm Trademark OULIN Origin China HS Code 84779000 Production Capacity 300-500 Sets Per Year

Product Description

Detail Information For Bimetal Screw and Barrel for High Speed Extrusion:

Application: for high speed extrusion extrusion

Customer's Requirement: good abrasive resistance.

Screw's quality: bimetallic quality, screw's alloy layer contains 30% tungsten carbide powder.

Barrel's quality: OLIN-AR02 bimetallic barrel, better abrasive resistance, medium corrosive resistance.



Detail Information For All Single Screw and barrel for Extrusion:

Main application: be used in extrusion for film, pipe, recycling, pelleting, sheet, profiles, rod and etc.

Specification:
Diameter: Ø20mm-Ø500mm
L/D ratio: 15-53

Base material :
SKD61
42CrMo
38CrMoAlA(JIS SACM645) from BAOSTEEL company.

Heat treatment:
Advance hardening and tempering
Nitriding treatment
Mid-frequency hardening

Technical Parameters:
Nitriding depth: 0.50mm-0.80mm
Nitriding hardness: HRC56-58
Surface roughness: Ra 0.4
Screw straightness: 0.015mm
Hard chrome layer hardness: HRC58-60
Hard chrome layer thickness: 0.025-0.1mm
Alloy layer depth: 2mm-3mm
Alloy layer hardness: HRC56-64



OULIN SCREW:  YOUR LOYAL PARTNER FOR SCREW AND BARREL

Bimetal Screw and Barrel for High Speed Extrusion
Bimetal Screw and Barrel for High Speed Extrusion
Bimetal Screw and Barrel for High Speed Extrusion
