• Model NO.：CHSJ--Y
• Machine Weight：4T
• Certification：CE, ISO9001:2008
• Diameter of Screw：55-65mm
• Rotation Speed of Screw：10-110r,Min
• Extrusion Capacity：46-70kg,H
• Maximum Folding Diameter of Film：750mmx2
• Single-Sided Thickness of Film：0.006-0.1mm
• Main Motor Power：15-22kw
• Transport Package：Wooden-Box,Nude
• Specification：SGS
• Trademark：Chengheng
• Origin：China
• HS Code：8477309000
• Production Capacity：100sets,Year

ModelY-55/600   Y-65/700   Width of the film
 T-shirt bag100-350mm  200-420mm Flat bag200-500mm   250-700mm Thickness of the film0.006-0.04mmThe max output45kg/h   55kg/h   75kg/h  85kg/h
According to different width,thickness of film, die size and raw material characteristics to changeRaw materialHDPE/LDPE/LLDPEPower consumption20kw/h  30kw/hWeight3500kg  4200kgOverall dimension(L*W*H)m5*2.1*4.3  5*2.2*4.5   Extruder unitDiameter of screwΦ55   Φ65
38CrMoALA  wearproof Alloy steel,five years guaranteeL/D ratio of screw30:1Rotation speed of screw10-120r/mBarrel FanZone 3 barrels install over-temperature fanGear box200#  225#
Extruder special hard gear reducer,tooth grinding teeth hardened, internal and external oil circulation systemMain motor30kw 37kw
100% Original three-phase variable frequency motor  Equipped with inverter controlDie head unitDie diameter50mm   60mm  80mm
With 40Cr steel forging finishing, eight feed trough runner,Uniform flow channel,blown plasticizing effectCool unitAir ring typeLDPE double vents vacuum air ring(HDPE)
HDPESingle outlet air ring(HDPE )Air ring materialHigh quality Taiwan cast aluminum alloy air ringBellow power1.5kw  4kw   2.2kw
Shanghai production of high-pressure mute fanTraction unitWidth of take up roller600mm  700mm Traction roller materialsilicone roller
NBR rollerTake up motor1.5kw  2.2kw  3.0kw
Installation of RV series reducer variable frequency motor inverter controlTake up speed100m/minEmbossing roller
 hot embossing unit
cold embossing unitLambdoidal boardWooden flannel wrappedGusset equipmentModular rack type
Independent Split  Bubble stabilizing ring
 Electric aluminum roller guide
Manual wood floor Guide rollerAluminum guide roller (HV300-HV700) surface treatmentWinding unitWinding typeSurface friction rewinding, manually change the volumeDrive typeTorque motor equipped RV reducerFilm expanding rollerSmoothing rollerElectric control cabinetlow-voltage is Universal electrical appliances, Delixi Electric, Taiwan's Yangming Electric, Huibang temperature control tableComputer control type()7-inch touch screen + process control system
Automatic air supply device Service
1.Free installation and ajustment.(for consumers purchase more than $100000 only)
2.One year free after-sales service(No charge for changing parts) and mechanical parts lifetime warranty.
3.We will offer you the professional answers about the relating machines in 24 hours.
