• Model NO.：HSD
• Transport Package：Standard Export Packing
• Specification：ISO9001-2008
• Trademark：Huashida
• Origin：Qingdao, China
• HS Code：8477209000
• Production Capacity：840kg,H

Basic Info.

Model NO. HSD Transport Package Standard Export Packing Specification ISO9001-2008 Trademark Huashida Origin Qingdao, China HS Code 8477209000 Production Capacity 840kg/H

Product Description

HDPE Pipe Production Line / Plastic Machinery Extrusion Machine


SKRG2000 HDPE Hollow Wall Corrugated Pipe produced by this line have high stiffness, high brunt intensity, and low weight due to it's unique structure. In addition, it has many advantages such as good creep deformation resistance, outer pressure resistance, erosion resistance(such as acid, alkali and salt etc), long life of approximate 50 years. It has been widely used for sewerage and drainage in municipal, it will replace the cement pipe, cast iron pipe and other pipes. It's low cost of assembling, easy operation, easy connection and economical construction can make it wide foreground and market potetial.

Features of HDPE Hollow Wall Corrugated Pipe: It's designed with advanced technology includes 1st single screw extruder for square shaped pipe, square shaped pipe extrusion die, vacuum calibration water tank, spray cooling water tank. 2ND single screww extruder for melting glue material, spiral forming unit, cutting and stack unit.

Model	Diameter(mm)	Style	Total Power	Extrusion Speed(m)	Capacity(kg/h)	Dimension (m)
SKRG2000	800-2000	SJ-100X33 SJ-65X33	400Kw	0.5-5	600 240	32x16x6.0
