• Model NO.：chsj-v
• Machine Weight：4T
• Certification：CE, ISO9001:2008
• Diameter of Screw：50,65mm*2
• Film Width：300-1600
• Film Thickness：0.007-0.05
• Extrusion Capacity：98-185kg
• Maximum Rotation Speed of Screw：120
• Traction Speed：15-70
• Weight：3.5-4.2t
• Transport Package：Wooden Case
• Specification：SGS
• Trademark：CHENGHENG
• Origin：Hebei Ningjin County
• HS Code：8477300000
• Production Capacity：200sets,Month

Model()
 V-40-45-40/900 V-50-65-50/1400
V-55-65-55/1600  V-65-75-65/1800Width of the film
()250-700mm   300-1200mm  500-1400mm 500-1600mmThickness of the film()0.006-0.15mmThe max output()115kg/h   135kg/h 155kg/h  175kg/h
According to different width,thickness of film, die size and raw material characteristics to change
(,,)Raw material()HDPE/LDPE/LDPEWeight()3800kg   5200kg  9800kg  10200kgOverall dimension(L*W*H)m
(**)6.5*2.7*5  6.5*3*5.8 6.5*3.8*6.2   6.8*4*6.8Extruder unit()Diameter of screw
()Φ40/45/40  Φ50/65/50   Φ55/65/55   Φ65/75/65
38CrMoALA  wearproof Alloy steel,five years guarantee
(38CrMoALA,)L/D ratio of screw
()30:1Rotation speed of screw
()10-120r/mBarrel Fan
()Zone 3 barrels install over-temperature fan
(3)Gear box()146#   173#   200#   225#
Extruder special hard gear reducer,tooth grinding teeth hardened, internal and external oil circulation system
(,,)Main motor()15kw    22kw    30kw   37kw
100% Original three-phase variable frequency motor  Equipped with inverter control
(100%   )Die head unit()Die diameter
()60mm   80mm  120mm 250mm  360mm
With 40Cr steel forging finishing, eight feed trough runner,Uniform flow channel,blown plasticizing effect
(40Cr,8,,)Cool unit()Air ring type
()LDPE double vents vacuum air ring(HDPE)
HDPE Single outlet air ring(HDPE )Air ring material
()High quality Taiwan cast aluminum alloy air ring
()Bellow power
()1.5kw  4kw   2.2kw   7.5kw   11kw
Shanghai production of high-pressure mute fan
()Traction unit()
 0.75KW
 0.5kw ×2
 ±350°
 ,.Width of take up roller
()900mm  1400mm   1600mm   1800mm Traction roller material
()silicone roll()
NBR roller()Take up motor
()1.5kw  2.2kw  3.0kw
Installation of RV series reducer variable frequency motor inverter control
(RV  )Take up speed
()100m/min
 1.5kw10N.m
 700mm  900mm   1200mm   1400mm Lambdoidal board
()Wooden flannel wrapped()
Aluminum roller guide  ( )
 Gusset equipment
()Modular rack type    ()
Independent Split  ()Bubble stabilizing ring
()Electric aluminum roller guide  ( )
Manual wood floor ()Guide roller()Aluminum guide roller (HV300-HV700) surface treatment
( (HV300-HV700))Winding unit()Winding type
()Surface friction rewinding, manually change the volume
(,)Drive type()Torque motor equipped RV reducer(RV)Film expanding roller()Smoothing roll()
 ,Electric control cabinet()low-voltage is Universal electrical appliances, Delixi Electric, Taiwan's Yangming Electric, Huibang temperature control table
(,,,)Computer control type()7-inch touch screen + process control system(7+)
Automatic air supply device ()Model()
 A-45/700   A-50/900    A-65/1200  A-75/1400Width of the film
()T-shirt bag()200-420mm  250-600mm  300-1000mm 500-1200mmFlat bag()200-600mm   250-800mm  500-1100mm 500-1300mmThickness of the film()0.006-0.04mmThe max output()45kg/h   55kg/h   75kg/h  85kg/h
According to different width,thickness of film, die size and raw material characteristics to change
(,,)Raw material()LDPEPower consumption()10kw/h   15kw/h  20kw/h  30kw/hWeight()2500kg   2800kg  3500kg  4200kgOverall dimension(L*W*H)m
(**)5*2.1*4.3  5*2.2*3.5    6.5*3.2*5.2   6.8*3.5*5.6Extruder unit()Diameter of screw
()Φ45   Φ50   Φ65  Φ75
38CrMoALA  wearproof Alloy steel,five years guarantee
(38CrMoALA,)L/D ratio of screw
()30:1Rotation speed of screw
()10-120r/mBarrel Fan
()Zone 3 barrels install over-temperature fan
(3)Gear box()146#  173#  200#  225#
Extruder special hard gear reducer,tooth grinding teeth hardened, internal and external oil circulation system
(,,)Main motor()11kw  15kw  30kw 37kw
100% Original three-phase variable frequency motor  Equipped with inverter control
(100%   )Die head unit()Die diameter
()50mm   60mm  80mm   100mm  120mm
With 40Cr steel forging finishing, eight feed trough runner,Uniform flow channel,blown plasticizing effect
(40Cr,8,,)Cool unit()Air ring type
()LDPE double vents vacuum air ring(HDPE)
HDPE Single outlet air ring(HDPE )Air ring material
()High quality Taiwan cast aluminum alloy air ring
()Bellow power
()1.5kw  4kw   2.2kw   7.5kw   11kw
Shanghai production of high-pressure mute fan
()Traction unit()Width of take up roller
()700mm  900mm   1200mm   1400mm Traction roller material
()silicone roll()
NBR roller()Take up motor
()1.5kw  2.2kw  3.0kw
Installation of RV series reducer variable frequency motor inverter control
(RV  )Take up speed
()100m/minEmbossing roller
()hot embossing unit (   )
cold embossing unit ()Lambdoidal board
()Wooden flannel wrapped()Gusset equipment
()Modular rack type    ()
Independent Split  ()Bubble stabilizing ring
()Electric aluminum roller guide  ( )
Manual wood floor ()Guide roller()Aluminum guide roller (HV300-HV700) surface treatment
( (HV300-HV700))Winding unit()Winding type
()Surface friction rewinding, manually change the volume
(,)Drive type()Torque motor equipped RV reducer(RV)Film expanding roller()Smoothing roll()Electric control cabinet()low-voltage is Universal electrical appliances, Delixi Electric, Taiwan's Yangming Electric, Huibang temperature control table
(,,,)Computer control type()7-inch touch screen + process control system(7+)
Automatic air supply device ()


Service;
1.Free installation and ajustment.(for consumers purchase more than $100000 only)
2.5 year free after-sales service(No charge for changing parts) and mechanical parts lifetime warranty.
3.We will offer you the professional answers about the relating machines in 24 hours.
Warm Noted:


Are you a factory or Trading Company
   We are a factory with experienced exporting products. We also help clients
   To look for products which they can not sure of.

Where is your factory Located
  Our Factory Located in Ningjin  City ,Hebei Province ,China .
  It is about 2 hours by plane from Shanghai,  about 3 hours by air plane from
  guangzhou .
  We are pleasured to pick up you when you arrived .




How you work if I am not come to China
   Usually , I will offer you our All Government Certificates (all Certificates are got after Government persons' Strict Investigation
to show that we are a true exist company,
Then I will show you machines that you want to buy on computer by video and pictures , So that If you have any questions or Good Ideas
on machines , we will discuss with engineers to offer you a well resolution .
When machines finished , If you are too busy to come To China , we can show you pictures and videos .If machines not good ,you can refuse
to pay us .
Surely , If it is no problem , you should pay us the rest 70% Before shipping .






IF Have more questions , Contact with me !!!
