2018 Xiongqiu Hot Sales High Speed Plastic HDPE LDPE PE PP Film Blowing Machine

Xiongqiu Plastic Machinery Co., Ltd.
  • Type：PP Film Blowing Machine
  • Raw Material：PP
  • Maximum Folding Width of Film：1100mm
  • Screw Diameter：85mm
  • Automation：Non-Automatic
  • Computerized：Computerized

Base Info

  • Model NO.：FMP-1000S3
  • Machine Weight：6t
  • Certification：CE, ISO9001:2008
  • Size：L*W*H: 6m * 3m * 4m
  • Voltage：380V 50Hz 3phase
  • Transport Package：Plastic Warp Film for Container Shipment
  • Specification：single layer
  • Trademark：Xiongqiu Plastic Machinery Co., Ltd.
  • Origin：Foshan, Guangdong Province
  • HS Code：8477800000

Description

PP / PPEthickness0.02--0.20mmfilm width(mm)60--400100--650150--700250--900300--1000max output40kgs/hr55kgs/hr70kgs/hr90kgs/hr120kgs/hr Extruder30:1temp. controller4 zone4 zone5 zone5 zone6 zonebarrel cooling120w*2120w*2120w*2250w*3250w*3driving motor11kw15kw18.5kw30kw45kw Die headSpiral mandrel die chrome plated surface 40Crcooling fan550w950w1.1kw1.5kw2.2kwTake up unit partauto-loader device, film surface treater, air compressor, rotary die head,automatic winder
pictures for reference:
2018 Xiongqiu Hot Sales High Speed Plastic HDPE LDPE PE PP Film Blowing Machine
2018 Xiongqiu Hot Sales High Speed Plastic HDPE LDPE PE PP Film Blowing Machine

2018 Xiongqiu Hot Sales High Speed Plastic HDPE LDPE PE PP Film Blowing Machine



2018 Xiongqiu Hot Sales High Speed Plastic HDPE LDPE PE PP Film Blowing Machine
2018 Xiongqiu Hot Sales High Speed Plastic HDPE LDPE PE PP Film Blowing Machine

2018 Xiongqiu Hot Sales High Speed Plastic HDPE LDPE PE PP Film Blowing Machine
