PP Bowl Robot Arm Stacker for Cup Tray Clamshell Thermoforming Machine in Factory
LX Plastic Machinery Co., Ltd.- Certification：CE
- Column number：Four Column
- Molding Method：Pressing
- Automatic Grade：Automatic
- Forming Area：720mm*430mm Max.,700*360mm Max.
- Forming Depth：180-200mm Max.
Base Info
- Dry Run Speed：40cycles,Min Max.
- Film Thickness：0.2-2.5mm
- Sheet Width：700mm Max.
- Suitable Material：PP PS Pet PVC
- Air Pressure：0.7MPa
- Production Range：Cup,Lid,Container, Clamshell and Tray
- Automaticity：Forming, Cutting, Stacking and Conveying
- Transport Package：Plastic Film with Anti-Rust Oil
- Specification：8500*2600*2200mm
- Trademark：LXPLASTIC
- Origin：China
- HS Code：8477409000
- Production Capacity：20sets,Year
Description
Useful Optional Items for Tilt-mold thermoforming machine
In-line Grinder with cyclone
Traveling crane for easy tool-change
Auto Cup packer
PP Pre-heater
