10000L Large HDPE Multiply Layers Water Tank Blow Molding Machine

Qingdao Yankang Plastic Machinery Co., Ltd.
  • Type：Extrusion Blow Molding Machine
  • Raw Material：HDPE
  • Making Method of Parison：Extrusion-Blow Molding
  • Automation：Automatic
  • Computerized：Computerized
  • Certification：CE, ISO9001:2008, QS

Base Info

  • Model NO.：YK10000L-3
  • 10000L：Three Layers
  • Transport Package：Wooden Packing or Nude Packing
  • Trademark：YANKANG
  • Origin：Qingdao
  • HS Code：8477301000
  • Production Capacity：30sets,Year

Description


PARISION CONTROL THINCKNESS CONTROLMOOGJAPANPLCSEIMENSGERMANYTEMPERATURE CONTROL MODULESEIMENSGERMANYSERVO VALVE & SERVO TRANSDUCERMIRANITALYINVERTERSEIMENSGERMANYHYDRAULIC OIL SEALDZTAIWANINTERMEDIATE RELAYOMRONJAPANPNEUMATIC VALVEAIRTECHTAIWANHYDRAULIC PUMP & VALVEYUKENJAPANPNEUMATIC SWITCH & CONTACTORSEIMENSGERMANYHYDRAULIC MOTOR & SCREW MOTORSEIMENSGERMANYREDUCERGUOMAOCHINA
6.SpecificationNo
 specifications10000 Liter

 Model No.3 layers

 Processing materialHDPE/HMWHDPE1ExtrudersGear Box TypeHard surfaceMax Screw Speed60RPM2Accumulator Die HeadHeating Load100kwDie-Core size [ Min / Max]∮500-1100MMInverterSiemensMax. parison weight300KG3Moulding Clamping UnitCLAMPING PLATEN Size3000X4000mmMAX MOLD SIZE2750X4000mmMould Clamping Force6000KNMould Thickness1700-24004Stretching and Blowing UnitSpreading stroke400-1200mmVertical stroke max.300mm5Electrical Control PanelThickness controller100 points MoogMain Operation PanelSiemensDie Head Control Temperature ControlSiemens6Hydraulic SystemHydraulic Drive motor (Main)55KWHydraulic Drive Motor (Parison Control)11kwOil Tank Capacity1800Lx27GripperGripped stroke650mm8Hopper LoaderLoader800kg/H 3pcsHopper50kg 3pcs9Production rate
Of 10000 ltr.Productivity2-3pcs/hProduct Weight170-180kg10Delivery period
 6 months11Weight of Machine
 190Ton
 Size of Machine[L x W x H ] (M)18mx14mx10m12Total power
 680KW13Average power Consumption
 420KW10000L Large HDPE Multiply Layers Water Tank Blow Molding Machine
10000L Large HDPE Multiply Layers Water Tank Blow Molding Machine
10000L Large HDPE Multiply Layers Water Tank Blow Molding Machine
10000L Large HDPE Multiply Layers Water Tank Blow Molding Machine
10000L Large HDPE Multiply Layers Water Tank Blow Molding Machine

DELIVERY TIME
6 months after the down payment;

TRAINNING
The Buyer could dispatch their operators to the Seller's factory for training, including machine operation, maintenance & simple repairs;
Or against the requests of the Buyer, the Seller's technician could train the Buyer's operators in the Buyer's factory in the periods of installing & adjusting;
The training is free of charge;

INSTALLATION & ADJUSTMENT
The Seller could dispatch an engineer against the requests of the Buyer to install and adjust the machines for one week in the Buyer's factory.
The Buyer should make a reservation in advance before delivery of the machines;
The Buyer should pay for the engineer's food & board while installation in buyer's factory.

GUARANTEE
The guarantee time is one and half year after the machines normally works in the Buyer's factory, if only the problem is cause due to quality control or any reason by the Seller. We will supply replaced parts free of charge and our engineers will guide you how to solve the problems.
Any problem caused due to irregular operation or incorrect maintenance by the Buyer won't be listed in guarantee coverage.
