• Condition：New
• High Capacity：400kg,Hr
• Transport Package：Wood
• Specification：sgs
• Trademark：middle tech
• Origin：Zhangjiagang City
• HS Code：84772090
• Production Capacity：250kg,Hr

Basic Info.

Condition New High Capacity 400kg/Hr Transport Package Wood Specification sgs Trademark middle tech Origin Zhangjiagang City HS Code 84772090 Production Capacity 250kg/Hr

Product Description

Product Description

Through market combination and continuous research innovation, Midtech pleased to provide energy saving (15% down), high standard (Bimetallic & PLC Intelligence), reliable quality (vertical gearbox by SKF bearing) extruder and whole set extrusion and production line
We are capable of producing pipe diameter up to 710mm for PVC pipe.

Our advantage:
--- Professional technician group ensure the performance of the machine
--- More than 10 years experience to cooperate with world famous factories
--- Advanced design for screws supplies powerful safeguard for the PVC plasticization.
--- Unique inside oil controlling temperature system adapts different technology formulas.
--- Special servo motor to ensure the haul off running
--- Special design of cutter ensure the cutting surface

Line description
For 16-63mm pipes, you can use SJSZ65/132 extruder. It can produce 2 pipes at the same time.
If use SJSZ80/156 extruder, pipe range is 16-63mm too. And it can produce 4 pipes at the same time.


The working process of PVC Twin Pipe Machinery:
Raw material+additive → mixing → screw feeding → conical double screw extruder → mould → vacuum formin table → haul-off unit → automatic cutting machine → stacker

Auxiliary equipments: mixer, printer, crusher, pulverizer, belling machine, etc.

Line configuration


Main  extruder	SJSZ-51/105	SJSZ-65/132	SJSZ-80/156	SJSZ-92/188
Main  motor  power(KW)	22	37	55	110
Pipe  diameter(mm)	16-63mm	75-160mm	200-400	400-630
Hauling  speed(m/min)	0.8-10	0.5-5	0.3-4	0.2-3
Max. Capacity(kg/h)	120	260	400	600
Total  power(KW)	89	95	135	255
