High Efficiency PLC Control Plastic Injection Mold Maker with India Price
Zhangjiagang Reliable Machinery Co., Ltd.- Type：Injection Blow Molding
- Structure：Horizontal
- Plastic Type：Thermoplastic
- Plasticizing Way：Plunger Type
- Clamping Way：Mechanical
- Automation：Automatic
Base Info
- Model NO.：RM-injection
- Computerized：Computerized
- Certification：CE, ISO9001:2008
- Processing：Injection Molding Machine
- Quality：High
- Injection Rate：35.2~51.8g,S
- Injection Weight：772~1050g
- Usage：Cap .Preform
- Warranty：1 Year
- Install：Yes
- Service：Good
- Transport Package：Wooden Packing
- Specification：SGS CE ISO
- Trademark：Reliable-machinery
- Origin：Zhangjiagang City, Jiangsu, China
- HS Code：8422301090
- Production Capacity：15 Sets , Month
Description
Item
Unit
Data
Max. clamping force
KN
5500
Max. opening force
mm
820
(V×H)Space between tie bars
mm
810×810
(min-max)Mould height
mm
350-820
Max. daylight
mm
1640
Ejector force
KN
150
Ejector stroke
mm
210
Ejector quantity
13
Screw diameter
mm
80
85
90
Screw L/D ratio
L/D
22.3
21
19.8
Theoretical shot volume
cm3
2141
2418
2710
Plasticising weight(PS)
g
1948
2200
2466
Injection pressure
Mpa
188
167
149
Theoretical injection rate(PS)
g
427
482
541
Plasticising capacity(PS)
g/s
80
100
118
Screw torque
N.m
5170
Max. screw rotate speed
r/min
150
Injection stroke
mm
425
Carriage push force
KN
175
Pump motor power
KW
55
Pump pressure
Mpa
16
Heating power
KW
33
Heating zone
6
Size (L×W×H)
m
8.4×2.2×2.6
Net weight
t
23.5
International designation
5500-4040
