Ght Straining Extruder for Soft PVC Film Calendering Line

Beijing Huatengzhengcheng Industry and Trade Co., Ltd.
  • Type：Sheet Extruder
  • Plastic Processed：PVC
  • Product Type：Extrusion Molding Machine
  • Feeding Mode：One Feed
  • Assembly Structure：Integral Type Extruder
  • Screw：Single-Screw

Base Info

  • Model NO.：GHT
  • Engagement System：Intermeshing
  • Screw Channel Structure：Deep Screw
  • Exhaust：Exhaust
  • Automation：Automatic
  • Computerized：Non-Computerized
  • Condition：New
  • Application：PVC Sheet
  • Brand Name：Ht
  • Place of Origin：Beijing China
  • Transport Package：Sea-Worthy Packing
  • Specification：CE
  • Trademark：HT
  • Origin：Beijing China
  • Production Capacity：10set,Year

Description

ModleScrew Diameter(mm)Screw L/D RatioMax. Rev of Screw(r/min)Driving Power(kw)Max. Output(kg/h)Dimension(L*W*H)Weight(ton)GHT2002005.5607512003500x1200x15005GHT25025066090/11020004000x1500x17006.5GHT30030066013228004500x1500x18007.5GHT35035066016033005000x1500x18009Function
It removes foreign materials and metallic particles that are mixed during the mixing process. In this way it protects the calender roll from damage.
Features of GHT straining extruder:


1.The screw is made of special steel by nitrogen treatment thus a more durable wear resistance.
2. Jacketed type barrel can be heated thus a good heat preservation of compound material.
3) Double die heads can be rapidly alternatively used,exit device of splitter plate can be operated quickly and easily.
5) Die auto switch on device in power failure to protect the machine.
